Omron V1000 User Manual

Item Specification
Environment
Storage/Installation Area Indoors
Ambient Temperature
-10 to +40 °C (wall-mounted enclosure)
-10 to +50 °C (open chassis)
Humidity 95% RH or less with no condensation
Storage Temperature -20 to +60 °C allowed for short-term transport of the product
Altitude 1000 m or less
Shock, Impact
10 to 20 Hz: 9.8 m/s
2
20 to 55 Hz: 5.9 m/s
2
Surrounding Area
Install the drive in an area free from:
• oil mist and dust
• metal shavings, oil, water or other foreign materials
• radioactive materials
• combustible materials
• harmful gases and liquids
• excessive vibration
• chlorides
• direct sunlight
Orientation Install the drive vertically to maintain maximum cooling effects
Safety Regulations and Standards
Safe Disable Input according to UL508C, EN954-1 Safety Category 3; EN61508, SIL2;
Time from input open to drive output stop is less than 1 ms.
Protective Enclosure
VZA4P0 drives and smaller: Open chassis/IP20
VZA5P5 drives and larger: Open chassis/NEMA 1
Cooling Method
VZAB0P1 to B0P7: self-cooled
VZAB1P5 to B4P0: cooling fan
VZA20P1 to 20P4: self-cooled
VZA20P7 to 2015: self-cooled
VZA40P2 to 40P7: self-cooled
VZA41P5 to 4015: self-cooled
<1> Speed control accuracy varies somewhat according to the type of motor and drive settings.
<2> Instantaneous average deceleration torque refers to the torque required to decelerate the motor (uncoupled from the load) from the rated motor
speed down to zero in the shortest time.
<3> Ensure that Stall Prevention Selection during Deceleration is disabled (L3-04 = 0) or set to 3 when using a braking resistor or the Braking
Resistor Unit. The default setting for the stall prevention function will interfere with the braking resistor.
<4> Overload protection may be triggered when operating with 150% of the rated output current if the output frequency is less than 6 Hz.
<5> Parameter settings allow up to 150 V.
<6> A Momentary Power Loss Ride-Thru Unit is required for 200/400 V class drives 7.5 kW and less if the application needs to continue running
during a momentary power loss up to 2 seconds.
<7> Ground protection cannot be provided under the following circumstances when a ground fault is likely in the motor windings during run: Low
ground resistance for the motor cable and terminal block; low ground resistance for the motor cable and terminal block; or the drive is powered
up from a ground short.
A.4 Drive Specifications
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
293
A
Specifications
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
