Table A.3 Power Ratings Continued
Item Specification
Three-Phase: VZA 25P5 27P5 2011 2015
Single-Phase VZA
<1>
- - - -
Maximum Motor Size Allowed (kW)
<3>
HD Rating 5.5 7.5 11.0 15.0
ND Rating 7.5 11.0 15.0 18.5
Input
Input Current (A)
<4>
Three-
Phase
HD Rating 26.0 35.4 51.9 70.8
ND Rating 34.7 50.9 69.4 85.6
Single-
Phase
HD Rating - - - -
ND Rating - - - -
Output
Rated Output Capacity (kVA)
<5>
HD Rating 9.5 12.6 17.9 22.9
ND Rating 11.4 15.2 21.3 26.3
Output Current (A)
HD Rating
25.0
<8>
33.0
<8>
47.0
<8>
60.0
<8>
ND Rating
<6>
30.0 40.0 56.0 69.0
Overload Tolerance
HD Rating: 150% of rated output current for 1 minute
ND Rating: 120% of rated output current for 1 minute
(Derating may be required for applications that start and stop frequently)
Carrier Frequency
User adjustable between 2 and 15 kHz (see HD output current line of this
table for default values)
Max Output Voltage (V) Three-phase 200 to 240 V (proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: Three-phase 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective Actions DC Reactor Optional
<1> Drives with single-phase power supply input will output three-phase power and cannot run a single-phase motor.
<3> The motor capacity (kW) refers to a Yaskawa 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor rated current.
<4> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.
<5> Rated motor capacity is calculated with a rated output voltage of 220 V.
<6> Carrier frequency is set to Swing PWM. Current derating is required in order to raise the carrier frequency.
<8> Carrier frequency is set to 8 kHz. Current derating is required in order to raise the carrier frequency.
Note: Differences between Heavy Duty (HD) ratings and Normal Duty (ND) ratings for the drive include rated input and output current, overload
capacity, carrier frequency and current limit. Set parameter C6-01 to “0” (default) for HD or “1” for ND.
A.2 Single/Three-Phase 200 V Class Drive
290
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
