Omron V1000 User Manual

n
Three-Phase 200 V
Heavy Duty Normal Duty
No.
Max Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
20P1 0.1 0.8 20P1 0.2 1.2
20P2 0.2 1.6 20P2 0.4 1.9
20P4 0.4 3.0 20P4 0.75 3.5
20P7 0.75 5.0 20P7 1.1 6.0
21P5 1.5 8.0 21P5 2.2 9.6
22P2 2.2 11.0 22P2 3.0 12.0
24P0 4.0 17.5 24P0 5.5 19.6
25P5 5.5 25.0 25P5 7.5 30.0
27P5 7.5 33.0 27P5 11 40.0
2011 11 47.0 2011 15 56.0
2015 15 60.0 2015 18.5 69.0
n
Three-Phase 400 V
Heavy Duty Normal Duty
No.
Max. Motor Capacity
kW
Rated Output
Current A
No.
Max. Motor Capacity
kW
Rated Output
Current A
40P2 0.2 1.2 40P2 0.4 1.2
40P4 0.4 1.8 40P4 0.75 2.1
40P7 0.75 3.4 40P7 1.5 4.1
41P5 1.5 4.8 41P5 2.2 5.4
42P2 2.2 5.5 42P2 3.0 6.9
43P0 3.0 7.2 43P0 4.0 8.8
44P0 4.0 9.2 44P0 5.5 11.1
45P5 5.5 14.8 45P5 7.5 17.5
47P5 7.5 18.0 47P5 11 23.0
4011 11 24.0 4011 15 31.0
4015 15 31.0 4015 18.5 38.0
<1> Drives with these specifications do not guarantee complete protection for the specified environmental condition.
Note: Refer to Component Names on page 22 for differences regarding enclosure protection types and component descriptions.
1.2 Model Number and Nameplate Check
20
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:22

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
