Omron V1000 User Manual

Table B.11 400 V, 1750 rpm Type Yaskawa SSR1 Series Motor
Par. Description Unit Default Settings
E5-01
Motor Code − 1232 1233 1235 1236 1238
Voltage class − 400 Vac 400 Vac 400 Vac 400 Vac 400 Vac
Rated power − 0.4 kW 0.75 kW 1.5 kW 2.2 kW 3.7 kW
Rated speed r/min 1750 1750 1750 1750 1750
E5-02 Motor rated power kW 0.4 0.75 1.5 2.2 3.7
E5-03 Motor rated current A 0.83 1.49 2.75 4.05 6.80
E5-04 Motor pole number – 6 6 6 6 6
E5-05 Motor winding resistance W 32.932 9.136 6.004 3.297 1.798
E5-06 d-axis inductance mH 219.36 92.08 68.32 40.39 32.93
E5-07 q-axis inductance mH 256.40 119.56 85.56 48.82 37.70
E5-09 Induction voltage constant 1 mVs/rad 466.0 459.0 501.8 485.7 498.7
E5-24 Induction voltage constant 2 mV/(r/min) 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 380.0 380.0 380.0 380.0 380.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum output frequency Hz 4.4 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.092 0.076 0.051 0.066 0.075
n8-49 Pull-in current % –7.2 –10.7 –11.1 –8.9 –7.9
Par. Description Unit Default Settings
E5-01
Motor Code − 123A 123B 123D 123E
Voltage class − 400 Vac 400 Vac 400 Vac 400 Vac
Rated power − 5.5 kW 7.5 kW 11 kW 15 kW
Rated speed r/min 1750 1750 1750 1750
E5-02 Motor rated power kW 5.5 7.5 11.0 15
E5-03 Motor rated current A 9.90 13.10 19.9 26.4
E5-04 Motor pole number – 6 6 6 6
E5-05 Motor winding resistance W 0.982 0.786 0.368 0.263
E5-06 d-axis inductance mH 22.7 16.49 13.38 10.51
E5-07 q-axis inductance mH 26.80 23.46 16.99 12.77
E5-09 Induction voltage constant 1 mVs/rad 498.0 541.7 508.7 531.9
E5-24 Induction voltage constant 2 mV/(r/min) 0.0 0.0 0.0 0.0
E1-04 Maximum output frequency Hz 87.5 87.5 87.5 87.5
E1-05 Maximum output voltage V 380.0 380.0 380.0 380.0
E1-06 Base voltage Hz 87.5 87.5 87.5 87.5
E1-09 Minimum output frequency Hz 4.4 4.4 4.4 4.4
L3-24 Motor acceleration time s 0.083 0.077 0.084 0.102
n8-49 Pull-in current % –10.2 –17.4 –15.8 –12.6
B.6 Parameters that Change with the Motor Code Selection
350
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
