H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description
Control
Mode
Pg.
V/f
OL
V
PM
1B Program Lockout
Open: Parameters can not be edited. (except U1-01 if reference source is
set for operator)
Closed: Parameters may be edited and saved.
O O O 165
1E Reference Sample Hold
Closed: Samples the analog frequency reference and operates the drive at
that speed.
O O O 165
20 to 2F External Fault
20: N.O., Always Detected, Ramp To Stop
21: N.C., Always Detected, Ramp To Stop
22: N.O., During Run, Ramp To Stop
23: N.C., During Run, Ramp To Stop
24: N.O., Always Detected, Coast To Stop
25: N.C., Always Detected, Coast To Stop
26: N.O., During Run, Coast To Stop
27: N.C., During Run, Coast To Stop
28: N.O., Always Detected, Fast-stop
29: N.C., Always Detected, Fast-stop
2A: N.O., During Run, Fast-stop
2B: N.C., During Run, Fast-stop
2C: N.O., Always Detected, Alarm Only (continue running)
2D: N.C., Always Detected, Alarm Only (continue running)
2E: N.O., During Run, Alarm Only (continue running)
2F: N.C., During Run, Alarm Only (continue running)
O O O 165
30 PID Integral Reset Closed: Resets the PID control integral value. O O O 166
31 PID Integral Hold Closed: Maintains the current PID control integral value. O O O 166
32 Multi-Step Speed Reference 4 Used to select Multi-Step Speeds set in d1-01 to d1-16 O O O 166
34 PID Soft Starter Closed: Disables the PID soft starter b5-17. O O O 166
35 PID Input Switch Closed: Inverses the PID input signal O O O 166
40
Forward Run Command (2-Wire
sequence)
Open: Stop
Closed: Forward run
Note: Can not be set together with Settings 42 or 43.
O O O 166
41
Reverse Run Command (2-Wire
sequence)
Open: Stop
Closed: Reverse run
Note: Can not be set together with Settings 42 or 43.
O O O 166
42 Run Command (2-Wire sequence 2)
Open: Stop
Closed: Run
Note: Can not be set together with Settings 40 or 41.
O O O 166
43
FWD/REV Command (2-Wire sequence
2)
Open: Forward
Closed: Reverse
Note: Can not be set together with Settings 40 or 41.
O O O 166
44 Offset Frequency 1 Addition Closed: Adds d7-01 to the frequency reference. O O O 167
45 Offset Frequency 2 Addition Closed: Adds d7-02 to the frequency reference. O O O 167
46 Offset Frequency 3 Addition Closed: Adds d7-03 to the frequency reference. O O O 167
60 DC Injection Braking Command Closed: Triggers DC Injection Braking (b2-02) O O - 167
61 External Search Command 1
Closed: Activates Current Detection Speed Search from the max. output
frequency (E1-04) if b3-01 = 0. Activates Speed Estimation Type Speed
search if b3-01 =1.
O O O 167
62 External Search Command 2
Closed: Activates Current Detection Speed Search from the frequency
reference b3-01 = 0. Activates Speed Estimation Type Speed search if
b3-01 =1.
O O O 167
65 KEB Ride-Thru 1 (N.C.)
Open: KEB Ride-Thru 1 enabled
Closed: Normal operation
O O O 167
66 KEB Ride-Thru 1 (N.O.)
Open: Normal operation
Closed: KEB Ride-Thru 1 enabled
O O O 167
67 Communications Test Mode Tests the MEMOBUS/Modbus RS-485/422 interface. O O O 167
68 High-Slip Braking Closed: High-Slip braking is executed. Drive stops. O - - 167
6A Drive Enable
Open: Drive disabled.
If this input is opened during run, then the drive will stop as specified by
parameter b1-03.
Closed: Ready for operation.
O O O 167
75 Up 2 Command Open: Maintains the current frequency reference.
Closed: Increases or decreases the frequency reference.
UP 2 and Down 2 commands must be set in combination with each other.
The frequency reference source must be assigned to the operator (b1-01
= “0”).
O O O 168
76 Down 2 Command O O O 168
7A KEB Ride-Thru 2 (N.C.)
Open: KEB Ride-Thru 2 enabled
Closed: Normal operation
O O O 168
7B KEB Ride-Thru 2 (N.O.)
Open: Normal operation
Closed: KEB Ride-Thru 2 enabled
O O O 168
7C Short-Circuit Braking (N.O.)
Open: Normal operation
Closed: Short-Circuit Braking
- - O 169
B.2 Parameter Table
316
