No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
P
M
F7-09 Gateway Address 1
Combining these parameters like F7-09.F7-10.F7-11.F7-12
sets the Ethernet Gateway Address.
Example: (192.168.1.1).
0 to 255
192
<60>
A A A 3ED 158
F7-10 Gateway Address 2 0 to 255
168
<60>
A A A 3EE 158
F7-11 Gateway Address 3 0 to 255
1
<60>
A A A 3EF 158
F7-12 Gateway Address 4 0 to 255
1
<60>
A A A 3F0 158
F7-13 Address Mode at Startup
Selects how the Ethernet IP address is set.
0: User defined
1: BOOTP
2: DHCP
0 to 2 0 A A A 3F1 158
F7-14
<59>
Duplex Mode Selection
0: Auto Negotiate
1: Half Duplex forced
2: Full Duplex forced
0 to 2 0 A A A 3F2 159
F7-15
<59>
Communication Speed
Selection
0: Auto Negotiate
10:10 Mbps speed setting
100: 100 Mbps Speed Setting
0, 10, 100 0 A A A 3F3 159
F7-16
<59>
Communication Loss
Timeout
Sets the timeout value for communication loss detection. 0 to 300 0 A A A 3F4 159
F7-17
<59>
Ethernet Speed Scaling
Factor
Sets the scaling factor for the speed monitor in Ethernet Class
ID 2AH Object.
-15 to 15 0 A A A 3F5 159
F7-18
<59>
Ethernet Current Scaling
Factor
Sets the scaling factor for the output current monitor in
Ethernet Class ID 2AH Object.
-15 to 15 0 A A A 3F6 159
F7-19
<59>
Ethernet Torque Scaling
Factor
Sets the scaling factor for the torque monitor in Ethernet
Class ID 2AH Object.
-15 to 15 0 A A A 3F7 159
F7-20
<59>
Ethernet Power Scaling
Factor
Sets the scaling factor for the power monitor in Ethernet
Class ID 2AH Object.
-15 to 15 0 A A A 3F8 159
F7-21
<59>
Ethernet Voltage Scaling
Factor
Sets the scaling factor for the voltage monitor in Ethernet
Class ID 2AH Object.
-15 to 15 0 A A A 3F9 159
F7-22
<59>
Ethernet Time Scaling
Sets the scaling factor for the time monitor in Ethernet Class
ID 2AH Object.
-15 to 15 0 A A A 3FA 159
<58> Valid from drive software 1011 and later. Parameters F6-50 to F6-54 had parameter numbers F6-20 to F6-24 in older software.
<59> Available in drive software 1011 and later.
<60> Default Setting valid for drive software 1011 and later.
B.2 Parameter Table
