Omron V1000 - Page 314

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
OL
V
P
M
F6-30 PROFIBUS node address Sets the node address for a PROFIBUS option. 0 to 125 0 A A A 3CB 156
F6-31
PROFIBUS Clear Mode
Selection
Selects the operation when a "Clear Mode" command is
received.
0: Resets drive operation.
1: Maintains the previous operation state.
0 or 1 0 A A A 3CC 156
F6-32
PROFIBUS Data Format
Selections
0: PPO Type
1: Conventional
0 or 1 0 A A A 3CD 156
F6-35 CANopen Node ID selection Sets the Node ID for a CANopen option 0 to 127 99 A A A 3D0 156
F6-36
CANopen Communications
speed
0: Auto-adjust
1: 10 kbps
2: 20 kbps
3: 50 kbps
4: 125 kbps
5: 250 kbps
6: 500 kbps
7: 800 kbps
8: 1 Mbps
0 to 8 6 A A A 3D1 156
F6-40 CompoNet Node ID Sets the Node ID for a CompoNet option. 0 to 63 0 A A A 3D5 156
F6-41 CompoNet Speed
0: 93.75 kbps
1: Reserved
2: 1.5 Mbps
3: 3 Mbps
4: 4 Mbps
5-255: Reserved
0 to 255 0 A A A 3D6 157
F6-50
<58>
DeviceNet MAC Address Selects the drives MAC address for DeviceNet. 0 to 63 0 A A A 3C1 157
F6-51
<58>
Device Net Communications
Speed
0: 125 kbps
1: 250 kbps
2: 500 kbps
3: Adjustable from Network
4: Detect automatically
0 to 4 3 A A A 3C2 157
F6-52
<58>
DeviceNet PCA setting I/O Polled Consuming Assembly Data Instance 0 to 255 0 A A A 3C3 157
F6-53
<58>
DeviceNet PPA setting I/O Polled Producing Assembly Data Instance 0 to 255 0 A A A 3C4 157
F6-54
<58>
DeviceNet Idle mode fault
detection
Selects if a EF0 fault is detected when no data are received
from the master.
0: Disabled
1: Enabled
0 or 1 0 A A A 3C5 157
F6-56
<59>
DeviceNet Speed Scaling
Factor
Sets the scaling factor for the speed monitor in DeviceNet
Class ID 2AH Object.
-15 to 15 0 A A A 3D7 157
F6-57
<59>
DeviceNet Current Scaling
Factor
Sets the scaling factor for the output current monitor in
DeviceNet Class ID 2AH Object.
-15 to 15 0 A A A 3D8 157
F6-58
<59>
DeviceNet Torque Scaling
Factor
Sets the scaling factor for the torque monitor in DeviceNet
Class ID 2AH Object.
-15 to 15 0 A A A 3D9 157
F6-59
<59>
DeviceNet Power Scaling
Factor
Sets the scaling factor for the power monitor in DeviceNet
Class ID 2AH Object.
-15 to 15 0 A A A 3DA 157
F6-60
<59>
DeviceNet Voltage Scaling
Factor
Sets the scaling factor for the voltage monitor in DeviceNet
Class ID 2AH Object.
-15 to 15 0 A A A 3DB 157
F6-61
<59>
DeviceNet Time Scaling
Factor
Sets the scaling factor for the time monitor in DeviceNet
Class ID 2AH Object.
-15 to 15 0 A A A 3DC 157
F6-62
<59>
DeviceNet Heartbeat Interval Sets the heartbeat interval for DeviceNet communications. 0 to 10 0 A A A 3DD 158
F7-01 Ethernet IP Address 1
Combining these parameters like F7-01.F7-02.F7-03.F7-04
sets the Ethernet IP address. Example: (192.168.1.10).
0 to 255
192
<60>
A A A 3E5 158
F7-02 Ethernet IP Address 1 0 to 255
168
<60>
A A A 3E6 158
F7-03 Ethernet IP Address 1 0 to 255
1
<60>
A A A 3E7 158
F7-04 Ethernet IP Address 1 0 to 255
20
<60>
A A A 3E8 158
F7-05 Subnet Mask 1
Combining these parameters like F7-05.F7-06.F7-07.F7-08
sets the Ethernet Subnet Mask.
Example: (255.255.255.0).
0 to 255
255
<60>
A A A 3E9 158
F7-06 Subnet Mask 2 0 to 255
255
<60>
A A A 3EA 158
F7-07 Subnet Mask 3 0 to 255
255
<60>
A A A 3EB 158
F7-08 Subnet Mask 4 0 to 255 0 A A A 3EC 158
B.2 Parameter Table
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
313
B
Parameter List
7/16/2008-13:23
