No. Name Setting Range Default
H6-05 Pulse Train Input Filter Time 0.00 to 2.00 s 0.10 s
n
H6-06: Pulse Train Output Terminal MP Monitor Selection
Selects the pulse train monitor output terminal MP function. The set value  is equal to the numerals in U- of
the selected monitor. Refer to U: Monitors on page 332 for a complete list of monitors. Selectable monitor items are
listed below.
No. Name Setting Range Default
H6-06 Pulse Train Output Terminal MP Monitor Selection
000, 031, 101, 102, 105, 116,
501, 502, 801 to 809
102
n
H6-07: Pulse Train Output Terminal MP Monitor Scaling
Pulse train monitor scaling sets the output frequency at terminal MP when the monitor item is 100%. Set H6-06 to 102
and H6-07 to 0 to make the pulse train monitor output synchronous to the output frequency.
No. Name Setting Range Default
H6-07 Pulse Train Input Monitor Scaling 0 to 32000 Hz 1440 Hz
5.7 H: Terminal Functions
184
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
