Omron V1000 User Manual

LED Operator Display Name
Minor Fault Output
(H2- = 10)
Page
UL3 Undertorque 1 YES 245
UL4 Undertorque 2 YES 246
UL5 Mechanical Weakening Detection 2 YES 239
Uv Undervoltage YES 246
n
Operation Errors
Table 6.7 Operation Error Displays
LED Operator
Display
Name Page
oPE01 Drive Unit Setting Error 247
oPE02 Parameter Setting Range Error 247
oPE03 Multi-Function Input Setting Error 247
oPE04 Terminal Board Mismatch Error 248
oPE05 Run Command Selection Error 248
oPE07
Multi-Function Analog Input
Selection Error
248
LED Operator
Display
Name Page
oPE08 Parameter Selection Error 248
oPE09 PID Control Selection Error 248
oPE10 V/f Data Setting Error 249
oPE11 Carrier Frequency Setting Error 249
oPE13 Pulse Train Monitor Selection Error 249
oPE14 Application Setup Error 249
n
Auto-Tuning Errors
Table 6.8 Auto-Tuning Error Displays
LED Operator
Display
Name Page
End1 Excessive V/f Setting 250
End2
Motor Iron Core Saturation
Coefficient Error
250
End3 Rated Current Setting Alarm 250
Er-01 Motor Data Error 250
Er-02 Alarm 250
Er-03 STOP button Input 250
LED Operator
Display
Name Page
Er-04 Line-to-Line Resistance Error 250
Er-05 No-Load Current Error 251
Er-08 Rated Slip Error 251
Er-09 Acceleration Error 251
Er-11 Motor Speed Error 251
Er-12 Current Detection Error 251
6.3 Drive Alarms, Faults, and Errors
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
229
6
Troubleshooting
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
