No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
b6-01 Dwell Reference at Start
The Dwell function is used to temporarily hold the frequency
when driving a motor with a heavy load.
Parameters b6-01 and b6-02 set the frequency to hold and the
time to maintain that frequency at start.
Parameters b6-03 and b6-04 set the frequency to hold and the
time to maintain that frequency at stop.
b6-01
b6-02
b6-03
b6-04
OFF
Run command
Output
Frequency
Time
ON
0.0 to
400.0
0.0
Hz
A A A 1B6 123
b6-02 Dwell Time at Start 0.0 to 10.0 0.0 s A A A 1B7 123
b6-03 Dwell Frequency at Stop
0.0 to
400.0
0.0
Hz
A A A 1B8 123
b6-04 Dwell Time at Stop 0.0 to 10.0 0.0 s A A A 1B9 123
b8: Energy Saving
Use b8 parameters to configure the energy saving/conservation drive function.
b8-01
Energy Saving Control
Selection
Selects the Energy Savings function.
0: Disabled
1: Enabled
0,1 0 A A − 1CC 123
b8-02
<22>
Energy Saving Gain
Sets energy savings control gain when in Open Loop Vector
Control.
0.0 to 10.0 0.7 − A − 1CD 123
b8-03
<22>
Energy Saving Control Filter
Time Constant
Sets energy saving control filter time constant when in Open
Loop Vector Control.
0.00 to
10.00
0.50
<12>
− A − 1CE 123
b8-04
Energy Saving Coefficient
Value
Sets the Energy Saving coefficient and is used to fine
adjustments in V/f Control.
0.0 to
655.00
<57>
<51>
A − − 1CF 124
b8-05 Power Detection Filter Time
Sets a filter time for the Power Detection used by Energy
Savings in V/f Control.
0 to 2000 20 ms A − − 1D0 124
b8-06
Search Operation Voltage
Limit
Sets the limit for the voltage search operation performed by
Energy Savings in V/f Control. Set as a percentage of the
motor base voltage. Disabled when set to 0%.
0 to 100 0% A − − 1D1 124
<1> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for A1-02 = 2-OLV control.
<2> Default setting value is dependent on parameter A1-02, Control Method Selection. The value shown is for A1-02 = 0-V/f Control.
<5> Default setting is dependent on parameter b5-20, PID Setpoint Scaling.
<12> Default setting value is dependent on parameter o2-04, Drive Model Selection.
<14> Default setting value is dependent on parameter o2-09, Initialization Spec. Selection.
<22> Parameter can be changed during run.
<32> A coasting motor may require a braking resistor circuit to bring the motor to a stop in the required time.
<33> Increase the setting value in increments of 0.1 when estimating the minimum output frequency for a motor coasting at high speed while
attempting Speed-Estimation Type Speed Search.
<34> Increase this value if an ov overvoltage fault occurs when performing Speed Search at start.
<51> Parameter value is changed if E2-11 is manuallychanged or changed by Auto-Tuning.
<57> Default setting value is dependent on parameter o2-04, Drive Model Selection and C6-01, Drive Duty Selection.
B.2 Parameter Table
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
303
B
Parameter List
7/16/2008-13:23
