No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
C3-05
Output Voltage Limit
Operation Selection
Selects if the motor magnetic flux is reduced during output
voltage saturation.
0: Disabled
1: Enabled
0,1
0
<2>
− A − 213 128
C4: Torque Compensation
Use C4 parameters to configure Torque Compensation function.
C4-01
<23>
Torque Compensation Gain
V/f Control: Sets the gain for the automatic torque
(voltage) boost function and helps to produce better
starting torque.
Increase this setting when using a long motor cable or
when the motor is significantly smaller than the drive
capacity.
Decrease this setting when motor oscillation occurs. Set
the value so that the current at low speed does not exceeds
the drives rated current.
Open Loop Vector: Sets the torque compensation function
gain. Normally no change is required.
0.00 to 2.50
1.00
<2>
A A A 215 128
C4-02
Torque Compensation
Primary Delay Time
Sets the torque compensation filter time.
Increase this setting when motor oscillation occurs.
Reduce the setting if there is not enough response from the
motor.
0 to 60000
200 ms
<1>
A A A 216 129
C4-03
Torque Compensation at
Forward Start
Sets torque compensation at forward start as a percentage
of motor torque.
0.0 to 200.0 0.0% − A − 217 129
C4-04
Torque Compensation at
Reverse Start
Sets torque compensation at reverse start as a percentage
of motor torque.
-200.0 to 0.0 0.0% − A − 218 129
C4-05
Torque Compensation Time
Constant
Sets the time constant for torque compensation at forward
start and reverse start (C4-03 and C4-04). The filter is
disabled if the time is set to 4 ms or less.
0 to 200 10 ms – A – 219 129
C4-06
Torque Compensation
Primary Delay Time 2
Sets the torque compensation time 2. When an ov fault
occurs with sudden load changes or at the and of an
acceleration, increase the setting.
Note: Adjustment is not normally required. If adjusted
then AFR time 2 (n2-03) should be adjusted too.
0 to 10000 150 ms – A – 21AH 129
C5: Speed Control (ASR)
Use C5 parameters to configure the Automatic Speed Regulator (ASR).
C5 parameters are available only when using V/f Control with Simple PG Feedback (H6-01 = 3).
C5-01
<22>
ASR Proportional Gain 1 Sets the proportional gain of the speed control loop (ASR).
0.00 to
300.00
0.20 A
– –
21B 130
C5-02
<22>
ASR Integral Time 1 Sets the integral time of the speed control loop (ASR).
0.000 to
10.000
0.200 A 21C 130
C5-03
<22>
ASR Proportional Gain 2
Sets the speed control gain 2 of the speed control loop
(ASR).
0.00 to
300.00
0.02 A − − 21D 131
C5-04
<22>
ASR Integral Time 2 Sets the integral time 2 of the speed control loop (ASR).
0.000 to
10.000
0.050 s A
– –
21E 131
C5-05
<22>
ASR Limit
Sets the upper limit for the speed control loop (ASR) as a
percentage of the maximum output frequency (E1-04).
0.0 to 20.0 5.0% A 21F 131
C6: Carrier Frequency
Use C6 parameters to configure the carrier frequency drive settings.
C6-01
Normal/Heavy Duty
Selection
Selects the load rating for the drive.
0: Heavy Duty (HD) for constant torque applications.
1: Normal Duty (ND) for variable torque applications.
This setting affects the Rated output current and overload
tolerance of the drive.
0,1 0 S S S 223 131
C6-02 Carrier Frequency Selection
Selects the carrier frequency
1 : 2.0 kHz
2 : 5.0 kHz
3 : 8.0 kHz
4 : 10.0 kHz
5 : 12.5 kHz
6 : 15.0 kHz
7 : Swing PWM1 (Audible sound 1)
8 : Swing PWM2 (Audible sound 2)
9 : Swing PWM3 (Audible sound 3)
A : Swing PWM4 (Audible sound 4)
B to E: No setting possible
F : User defined (determined by C6-03 through C6-05)
1 to F
<3>
S S S 224 132
B.2 Parameter Table
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
305
B
Parameter List
