Omron V1000 User Manual

No. Name Description Range Def.
Control
Mode
Addr.
Hex
Pg.
V/f
O
LV
P
M
d1-11
<22>
Frequency Reference 11
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 4" (H1- = 4 and 32) are on.
0.00 to
400.00 Hz
<11> <19>
0.00
Hz
A A A 28C 135
d1-12
<22>
Frequency Reference 12
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2, 4" (H1- = 3, 4, 32) are on.
0.00
Hz
A A A 28D 135
d1-13
<22>
Frequency Reference 13
Frequency reference when digital inputs "Multi-Step Speed
Reference 3, 4" (H1- = 5 and 32) are on.
0.00
Hz
A A A 28E 135
d1-14
<22>
Frequency Reference 14
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 3, 4" (H1- = 3, 5, 32) are on.
0.00
Hz
A A A 28F 135
d1-15
<22>
Frequency Reference 15
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 3, 4" (H1- = 4, 5, 32) are on.
0.00
Hz
A A A 290 135
d1-16
<22>
Frequency Reference 16
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2, 3, 4" (H1- = 3, 4, 5, 32) are on.
0.00
Hz
A A A 291 135
d1-17
<22>
Jog Frequency Reference
Frequency reference when digital inputs "Jog Frequency
Reference", "Forward Jog" or "Reverse Jog." are on. "Jog
Frequency Reference" has priority over "Multi-Step Speed
Reference 1 to 16”.
6.00
Hz
S S S 292 135
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01
Frequency Reference
Upper Limit
Sets the frequency reference upper limit as a percentage of
maximum output frequency (E1-04). Output speed is limited to
this value even if the frequency reference is higher. This limit
applies to all frequency reference sources.
0.0 to
110.0
100.0
%
A A A 289 136
d2-02
Frequency Reference
Lower Limit
Sets the frequency reference lower limit as a percentage of
maximum output frequency (E1-04). Output speed is limited to
this value even if the frequency reference is lower. This limit
applies to all frequency reference sources.
0.0 to
110.0
0.0% A A A 28A 136
d2-03
Master Speed Reference
Lower Limit
Sets the minimum frequency reference lower limit if the
frequency reference is input using an analog input. Set as a
percentage of maximum output frequency (E1-04). The higher
of both values d2-01 and d2-03 will be the lower limit.
0.0 to
110.0
0.0% A A A 293 136
d3: Jump Frequency
Use d3 parameters to configure the drive Jump Frequency settings.
d3-01 Jump Frequency 1 d3-01 to d3-04 allow programming of three prohibited
frequency reference points for eliminating problems with
resonant vibration of the motor / machine. This feature does not
eliminate the selected frequency values, but accelerates and
decelerates the motor through the prohibited bandwidth.
The parameters must be according to the rule
d3-01 ≥ d3-02 ≥ d3-03.
0.0 to
400.0
0.0 Hz A A A 294 137
d3-02 Jump Frequency 2 0.0 Hz A A A 295 137
d3-03 Jump Frequency 3 0.0 Hz A A A 296 137
d3-04 Jump Frequency Width
This parameter sets the dead-band width around each selected
prohibited frequency reference point. The bandwidth becomes
the designated Jump frequency, plus or minus d3-04.
0.0 to 20.0 1.0 Hz A A A 297 137
d4: Frequency Reference Hold
Use d4 parameters to configure the drive frequency reference hold function.
d4-01
Frequency Reference Hold
Function Selection
Determines if the frequency reference or frequency reference
bias is saved when the Run command is removed or the power
goes off.
0: Disabled
1: Enabled
This parameter is effective when the multi-function inputs
“Accel/Decel Ramp Hold”, “Up/Down” or “Up/Down 2”
commands are selected (H1- = A or 10/11 or 75/76).
0,1 0 A A A 298 137
d4-03
<22>
Frequency Reference Bias
Step (Up/Down 2)
Sets the bias added to the frequency reference when the Up/
Down 2 digital inputs are set.
When set to 0.00 Hz, the bias value is increased or decreased
according to d4-04.
When greater than 0.0 Hz, the bias value d4-03 is added or
subtracted to/from the frequency reference. The acceleration or
deceleration rate is ultimately determined by d4-04.
0.00 to
99.99 Hz
0.00
Hz
A A A 2AA 140
d4-04
<22>
Frequency Reference Bias
Accel/Decel (Up/Down 2)
Selects how the bias or frequency reference is increased when
using the Up/Down 2 function.
0: Use selected accel/decel time.
1: Use Accel/Decel Time 4 (C1-07 and C1-08).
0,1 0 A A A 2AB 140
d4-05
<22>
Frequency Reference Bias
Operation Mode Selection
(Up/Down 2)
0: Bias value is held if no input Up 2 or Down 2 is active.
1: When the Up 2 reference and Down 2 reference are both on
or both off, the applied bias becomes 0.
Currently selected accel / decel. times are used. Enabled only
when d4-03 = 0.
0,1 0 A A A 2AC 140
d4-06
Frequency Reference Bias
(Up/Down 2)
The Up/Down 2 bias value is saved in d4-06 when the
frequency reference is not input by the digital operator. The
function depends on the setting of d4-01.
It is limited by d4-08 and d4-09.
-99.9 to
+100.0
0.0% A A A 2AD 141
B.2 Parameter Table
SIEP C710606 20 OYMC AC Drive - V1000 User Manual
307
B
Parameter List
7/16/2008-13:23

Omron V1000 Specifications

General

Cooling Method	Fan cooling
Enclosure Rating	IP20
Communication	Modbus RTU
Output Power	0.4-15kW
Output Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Supply Voltage	200-240V AC (3-phase)
