Oracle SuperCluster T5-8 User Manual

Preparing for Cooling
Low Voltage High Voltage
PDU A PDU B Warning (Amps) Alarm (Amps) Warning (Amps) Alarm (Amps)
M1-2 M2-2 17 22 8 10
M1-1 M2-1 17 22 10 14
PDU Thresholds (Fully-Populated Racks)
TABLE 15
22kVA Single-Phase PDUs
Low Voltage High Voltage
PDU A PDU B Warning (Amps) Alarm (Amps) Warning (Amps) Alarm (Amps)
M1-3 M1-1 34 36 31 32
M1-2 M1-2 32 36 29 32
M1-1 M1-3 26 33 24 30
TABLE 16
24kVA 3-Phase PDUs
Low Voltage High Voltage
PDU A PDU B Warning (Amps) Alarm (Amps) Warning (Amps) Alarm (Amps)
M2-3 M1-3 30 35 15 18
M2-2 M1-2 31 35 17 18
M2-1 M1-1 29 35 16 18
M1-3 M2-3 25 32 14 17
M1-2 M2-2 23 29 14 17
M1-1 M2-1 23 29 10 14
Related Information
■
“PDU Power Requirements” on page 101
■
“Facility Power Requirements” on page 100
■
“Grounding Requirements” on page 100
■
“Power Consumption” on page 99
Preparing for Cooling
■
“Environmental Requirements” on page 107
■
“Heat Dissipation and Airflow Requirements” on page 107
106 Oracle SuperCluster T5-8 Owner's Guide • May 2016
