Oracle SuperCluster T5-8 User Manual

Six-Rack Cabling
Leaf Switch Connection Cable Length
R5-U32-P9B to R1-U1-P6A
R5 U32 to Rack 2 R5-U32-P10A to R2-U1-P7A
R5-U32-P10B to R2-U1-P8A
10 meters
R5 U32 to Rack 3 R5-U32-P11A to R3-U1-P9A 5 meters
R5 U32 to Rack 4 R5-U32-P11B to R4-U1-P10A 5 meters
R5 U26 within Rack 5 R5-U26-P8A to R5-U1-P3B
R5-U26-P8B to R5-U1-P4B
3 meters
R5 U26 to Rack 1 R5-U26-P9A to R1-U1-P5B
R5-U26-P9B to R1-U1-P6B
10 meters
R5 U26 to Rack 2 R5-U26-P10A to R2-U1-P7B
R5-U26-P10B to R2-U1-P8B
10 meters
R5 U26 to Rack 3 R5-U26-P11A to R3-U1-P9B 5 meters
R5 U26 to Rack 4 R5-U26-P11B to R4-U1-P10B 5 meters
Six-Rack Cabling
The following table shows the cable connections for the first spine switch (R1-U1) when
cabling six full racks together.
TABLE 36
Leaf Switch Connections for the First Rack in a Six-Rack System
Leaf Switch Connection Cable Length
R1 U32 within Rack 1 R1-U32-P8A to R1-U1-P3A
R1-U32-P8B to R1-U1-P4A
3 meters
R1 U32 to Rack 2 R1-U32-P9A to R2-U1-P5A
R1-U32-P9B to R2-U1-P6A
5 meters
R1 U32 to Rack 3 R1-U32-P10A to R3-U1-P7A 5 meters
R1 U32 to Rack 4 R1-U32-P10B to R4-U1-P8A 10 meters
R1 U32 to Rack 5 R1-U32-P11A to R5-U1-P9A 10 meters
R1 U32 to Rack 6 R1-U32-P11B to R6-U1-P10A 10 meters
R1 U26 within Rack 1 R1-U26-P8A to R1-U1-P3B
R1-U26-P8B to R1-U1-P4B
3 meters
R1 U26 to Rack 2 R1-U26-P9A to R2-U1-P5B
R1-U26-P9B to R2-U1-P6B
5 meters
Connecting Multiple Oracle SuperCluster T5-8 Systems 273
