Oracle SuperCluster T5-8 - PDU Power Requirements

Reviewing Power Requirements
■
“Power Consumption” on page 99
■
“PDU Power Requirements” on page 101
PDU Power Requirements
When ordering the system you selected one of these options:
■
Low or high voltage
■
Single or three phase power
Refer to the following tables for Oracle marketing and manufacturing part numbers.
Note - Each system has two power distribution units (PDUs). Both PDUs in a rack must be the
same type.
TABLE 6
PDU Choices
Voltage Phases Reference
Low 2 Table 7, “Low Voltage 2 Phase PDUs,” on page 101
Low 3 Table 8, “Low Voltage 3 Phase PDUs,” on page 102
High 1 Table 9, “High Voltage 1 Phase PDUs,” on page 103
High 3 Table 10, “High Voltage 3 Phase PDUs,” on page 103
TABLE 7
Low Voltage 2 Phase PDUs
Low Voltage Dual Phase (2W+GND) Comments
kVA Size 22 kVA
Marketing part number 7100873
Manufacturing part number 7018123
Phase 2 No Grounded Neutral provided in input
cords
Voltage input rating 3x [2Ph. (2W+ground)] 208 Vac, 50/60 Hz,
max. 36.8A per phase
Can be connected to Ph-Ph input sources in
range of 200V - 240V AC nominal
Amps per PDU 110.4A (3 inputs x 36.8A)
Outlets 42 C13
6 C19
Number of inputs 3 inputs x50A plug, 2Ph (2W+ground) 3 inputs/plugs per PDU, or 6 total inputs/
plugs for system
Input current 36.8A max. current (per input)
Data center receptacle Hubbell CS8264C
