Connecting an Expansion Rack to Oracle SuperCluster T5-8
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 131
Leaf Switch Connections for the Eighteenth Rack in the System
Leaf Switch Connection
R18 IB3 to Rack 1 R18-IB3-P8B to R1-IB1-P2A
R18 IB3 to Rack 2 R18-IB3-P9A to R2-IB1-P2A
R18 IB3 to Rack 3 R18-IB3-P9B to R3-IB1-P2A
R18 IB3 to Rack 4 R18-IB3-P10A to R4-IB1-P2A
R18 IB3 to Rack 5 R18-IB3-P10B to R5-IB1-P2A
R18 IB3 to Rack 6 R18-IB3-P2A to R6-IB1-P2A
R18 IB3 to Rack 7 R18-IB3-P2B to R7-IB1-P2A
R18 IB3 to Rack 8 R18-IB3-P8A to R8-IB1-P2A
R18 IB2 to Rack 1 R18-IB2-P8B to R1-IB1-P2B
R18 IB2 to Rack 2 R18-IB2-P9A to R2-IB1-P2B
R18 IB2 to Rack 3 R18-IB2-P9B to R3-IB1-P2B
R18 IB2 to Rack 4 R18-IB2-P10A to R4-IB1-P2B
R18 IB2 to Rack 5 R18-IB2-P10B to R5-IB1-P2B
R18 IB2 to Rack 6 R18-IB2-P2A to R6-IB1-P2B
R18 IB2 to Rack 7 R18-IB2-P2B to R7-IB1-P2B
R18 IB2 to Rack 8 R18-IB2-P8A to R8-IB1-P2B
352 Oracle SuperCluster T5-8 Owner's Guide • May 2016
