Understanding Expansion Rack Internal Cabling
Single-Phase PDU Cabling
This topic contains tables that list the single-phase cabling from each PDU to the power
supplies configured in each rack. The cables are terminated to PDU-A on the left, and routed to
the right to enter CMA, and are bundled in groups of four.
■
Table 77, “Single-Phase PDU Cabling for the Expansion Rack (Full Rack),” on page 308
■
Table 78, “Single-Phase PDU Cabling for the Expansion Rack (Half Rack),” on page 309
■
Table 79, “Single-Phase PDU Cabling for the Expansion Rack (Quarter Rack),” on page
309
TABLE 77
Single-Phase PDU Cabling for the Expansion Rack (Full Rack)
Rack Unit PDU-A/PS-00 PDU-B/PS-01 Cable Length
U41 G5-6 G0-0 2 meters
U39 G5-3 G0-3 2 meters
U37 G5-0 G0-6 2 meters
U35 G4-6 G1-0 2 meters
U33 G4-4 G1-2 2 meters
U31 G4-2 G1-4 2 meters
U29 G3-6 G2-0 2 meters
U27 G3-5 G2-1 2 meters
U25 G3-3 G2-3 2 meters
U24 G3-1 G2-5 2 meters
U23 N/A G3-0 included
U22 G2-5 G3-1 1 meter
U21 G3-0 G2-6 2 meters
U20 G2-4 G3-2 2 meters
U18 G2-2 G3-4 2 meters
U16 G1-6 G4-0 2 meters
U14 G2-0 G3-6 2 meters
U12 G1-4 G4-2 2 meters
U10 G1-2 G4-4 2 meters
U8 G1-0 G4-6 2 meters
U6 G0-6 G5-0 2 meters
U4 G0-4 G5-2 2 meters
U2 G0-2 G5-4 2 meters
U1 G0-0 G5-6 2 meters
308 Oracle SuperCluster T5-8 Owner's Guide • May 2016
