Eight-Rack Cabling
Leaf Switch Connection Cable Length
R6 U26 to Rack 7 R6-U26-P9A to R7-U1-P5B 5 meters
The following table shows the cable connections for the seventh spine switch (R7-U1) when
cabling seven full racks together.
TABLE 48
Leaf Switch Connections for the Seventh Rack in a Seven-Rack System
Leaf Switch Connection Cable Length
R7 U32 within Rack 7 R7-U32-P8A to R7-U1-P3A
R7-U32-P8B to R7-U1-P4A
3 meters
R7 U32 to Rack 1 R7-U32-P9A to R1-U1-P5A 10 meters
R7 U32 to Rack 2 R7-U32-P9B to R2-U1-P6A 10 meters
R7 U32 to Rack 3 R7-U32-P10A to R3-U1-P7A 10 meters
R7 U32 to Rack 4 R7-U32-P10B to R4-U1-P8A 10 meters
R7 U32 to Rack 5 R7-U32-P11A to R5-U1-P9A 5 meters
R7 U32 to Rack 6 R7-U32-P11B to R6-U1-P10A 5 meters
R7 U26 within Rack 7 R7-U26-P8A to R7-U1-P3B
R7-U26-P8B to R7-U1-P4B
3 meters
R7 U26 to Rack 1 R7-U26-P9A to R1-U1-P5B 10 meters
R7 U26 to Rack 2 R7-U26-P9B to R2-U1-P6B 10 meters
R7 U26 to Rack 3 R7-U26-P10A to R3-U1-P7B 10 meters
R7 U26 to Rack 4 R7-U26-P10B to R4-U1-P8B 10 meters
R7 U26 to Rack 5 R7-U26-P11A to R5-U1-P9B 5 meters
R7 U26 to Rack 6 R7-U26-P11B to R6-U1-P10B 5 meters
Eight-Rack Cabling
The following table shows the cable connections for the first spine switch (R1-U1) when
cabling eight full racks together.
TABLE 49
Leaf Switch Connections for the First Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R1 U32 within Rack 1 R1-U32-P8A to R1-U1-P3A 3 meters
R1 U32 to Rack 2 R1-U32-P8B to R2-U1-P4A 5 meters
R1 U32 to Rack 3 R1-U32-P9A to R3-U1-P5A 5 meters
R1 U32 to Rack 4 R1-U32-P9B to R4-U1-P6A 10 meters
Connecting Multiple Oracle SuperCluster T5-8 Systems 281
