Seven-Rack Cabling
Leaf Switch Connection Cable Length
R5-U32-P8B to R5-U1-P4A
R5 U32 to Rack 1 R5-U32-P10A to R1-U1-P7A 10 meters
R5 U32 to Rack 2 R5-U32-P10B to R2-U1-P8A 10 meters
R5 U32 to Rack 3 R5-U32-P11A to R3-U1-P9A 5 meters
R5 U32 to Rack 4 R5-U32-P11B to R4-U1-P10A 5 meters
R5 U32 to Rack 6 R5-U32-P9A to R6-U1-P5A 5 meters
R5 U32 to Rack 7 R5-U32-P9B to R7-U1-P6A 5 meters
R5 U26 within Rack 5 R5-U26-P8A to R5-U1-P3B
R5-U26-P8B to R5-U1-P4B
3 meters
R5 U26 to Rack 1 R5-U26-P10A to R1-U1-P7B 10 meters
R5 U26 to Rack 2 R5-U26-P10B to R2-U1-P8B 10 meters
R5 U26 to Rack 3 R5-U26-P11A to R3-U1-P9B 5 meters
R5 U26 to Rack 4 R5-U26-P11B to R4-U1-P10B 5 meters
R5 U26 to Rack 6 R5-U26-P9A to R6-U1-P5B 5 meters
R5 U26 to Rack 7 R5-U26-P9B to R7-U1-P6B 5 meters
The following table shows the cable connections for the sixth spine switch (R6-U1) when
cabling seven full racks together.
TABLE 47
Leaf Switch Connections for the Sixth Rack in a Seven-Rack System
Leaf Switch Connection Cable Length
R6 U32 within Rack 6 R6-U32-P8A to R6-U1-P3A
R6-U32-P8B to R6-U1-P4A
3 meters
R6 U32 to Rack 1 R6-U32-P9B to R1-U1-P6A 10 meters
R6 U32 to Rack 2 R6-U32-P10A to R2-U1-P7A 10 meters
R6 U32 to Rack 3 R6-U32-P10B to R3-U1-P8A 5 meters
R6 U32 to Rack 4 R6-U32-P11A to R4-U1-P9A 5 meters
R6 U32 to Rack 5 R6-U32-P11B to R5-U1-P10A 5 meters
R6 U32 to Rack 7 R6-U32-P9A to R7-U1-P5A 5 meters
R6 U26 within Rack 6 R6-U26-P8A to R6-U1-P3B
R6-U26-P8B to R6-U1-P4B
3 meters
R6 U26 to Rack 1 R6-U26-P9B to R1-U1-P6B 10 meters
R6 U26 to Rack 2 R6-U26-P10A to R2-U1-P7B 10 meters
R6 U26 to Rack 3 R6-U26-P10B to R3-U1-P8B 5 meters
R6 U26 to Rack 4 R6-U26-P11A to R4-U1-P9B 5 meters
R6 U26 to Rack 5 R6-U26-P11B to R5-U1-P10B 5 meters
280 Oracle SuperCluster T5-8 Owner's Guide • May 2016
