Reviewing System Specifications
Location Maintenance Access
Rear maintenance 914 mm 36 in.
Front maintenance 914 mm 36 in.
Top maintenance 914 mm 36 in.
Related Information
■
“Physical Specifications” on page 96
■
“Rack and Floor Cutout Dimensions” on page 97
Rack and Floor Cutout Dimensions
If you plan to route cables down through the bottom of the rack, cut a rectangular hole in the
floor tile. Locate the hole below the rear portion of the rack, between the two rear casters and
behind the rear inner rails. The suggested hole width is 280 mm (11 inches).
If you want a separate grounding cable, see “Install a Ground Cable (Optional)” on page 124.
Caution - Do not create a hole where the rack casters or leveling feet will be placed.
Preparing the Site 97
