Connecting an Expansion Rack to Oracle SuperCluster T5-8
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 123
Leaf Switch Connections for the Tenth Rack in the System
Leaf Switch Connection
R10 IB3 to Rack 1 R10-IB3-P8B to R1-IB1-P12A
R10 IB3 to Rack 2 R10-IB3-P9A to R2-IB1-P12A
R10 IB3 to Rack 3 R10-IB3-P9B to R3-IB1-P12A
R10 IB3 to Rack 4 R10-IB3-P10A to R4-IB1-P12A
R10 IB3 to Rack 5 R10-IB3-P10B to R5-IB1-P12A
R10 IB3 to Rack 6 R10-IB3-P12A to R6-IB1-P12A
R10 IB3 to Rack 7 R10-IB3-P12B to R7-IB1-P12A
R10 IB3 to Rack 8 R10-IB3-P8A to R8-IB1-P12A
R10 IB2 to Rack 1 R10-IB2-P8B to R1-IB1-P12B
R10 IB2 to Rack 2 R10-IB2-P9A to R2-IB1-P12B
R10 IB2 to Rack 3 R10-IB2-P9B to R3-IB1-P12B
R10 IB2 to Rack 4 R10-IB2-P10A to R4-IB1-P12B
R10 IB2 to Rack 5 R10-IB2-P10B to R5-IB1-P12B
R10 IB2 to Rack 6 R10-IB2-P12A to R6-IB1-P12B
R10 IB2 to Rack 7 R10-IB2-P12B to R7-IB1-P12B
R10 IB2 to Rack 8 R10-IB2-P8A to R8-IB1-P12B
Eleven-Rack Cabling
The following table shows the cable connections for the switches when cabling eleven racks
together.
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 124
Leaf Switch Connections for the Eleventh Rack in the System
Leaf Switch Connection
R11 IB3 to Rack 1 R11-IB3-P8B to R1-IB1-P13A
R11 IB3 to Rack 2 R11-IB3-P9A to R2-IB1-P13A
R11 IB3 to Rack 3 R11-IB3-P9B to R3-IB1-P13A
R11 IB3 to Rack 4 R11-IB3-P10A to R4-IB1-P13A
346 Oracle SuperCluster T5-8 Owner's Guide • May 2016
