Four-Rack Cabling
Leaf Switch Connection Cable Length
R3-U32-P11B to R2-U1-P10A
R3-U26 within Rack 3 R3-U26-P8A to R3-U1-P3B
R3-U26-P8B to R3-U1-P4B
R3-U26-P9A to R3-U1-P5B
5 meters
R3-U26 to Rack 1 R3-U26-P9B to R1-U1-P6B
R3-U26-P10A to R1-U1-P7B
R3-U26-P10B to R1-U1-P8B
5 meters
R3-U26 to Rack 2 R3-U26-P11A to R2-U1-P9B
R3-U26-P11B to R2-U1-P10B
5 meters
Four-Rack Cabling
The following table shows the cable connections for the first spine switch (R1-U1) when
cabling four full racks together.
TABLE 27
Leaf Switch Connections for the First Rack in a Four-Rack System
Leaf Switch Connection Cable Length
R1-U32 within Rack 1 R1-U32-P8A to R1-U1-P3A
R1-U32-P8B to R1-U1-P4A
5 meters
R1-U32 to Rack 2 R1-U32-P9A to R2-U1-P5A
R1-U32-P9B to R2-U1-P6A
5 meters
R1-U32 to Rack 3 R1-U32-P10A to R3-U1-P7A
R1-U32-P10B to R3-U1-P8A
5 meters
R1-U32 to Rack 4 R1-U32-P11A to R4-U1-P9A
R1-U32-P11B to R4-U1-P10A
10 meters
R1-U26 within Rack 1 R1-U26-P8A to R1-U1-P3B
R1-U26-P8B to R1-U1-P4B
5 meters
R1-U26 to Rack 2 R1-U26-P9A to R2-U1-P5B
R1-U26-P9B to R2-U1-P6B
5 meters
R1-U26 to Rack 3 R1-U26-P10A to R3-U1-P7B
R1-U26-P10B to R3-U1-P8B
5 meters
R1-U26 to Rack 4 R1-U26-P11A to R4-U1-P9B 10 meters
Connecting Multiple Oracle SuperCluster T5-8 Systems 267
