Oracle SuperCluster T5-8 User Manual

Three-Rack Cabling
The following table shows the cable connections for the second spine switch (R2-U1) when
cabling three racks together.
TABLE 25
Leaf Switch Connections for the Second Rack in a Three-Rack System
Leaf Switch Connection Cable Length
R2-U32 within Rack 2 R2-U32-P8A to R2-U1-P3A
R2-U32-P8B to R2-U1-P4A
R2-U32-P9A to R2-U1-P5A
5 meters
R2-U32 to Rack 1 R2-U32-P11A to R1-U1-P9A
R2-U32-P11B to R1-U1-P10A
5 meters
R2-U32 to Rack 3 R2-U32-P9B to R3-U1-P6A
R2-U32-P10A to R3-U1-P7A
R2-U32-P10B to R3-U1-P8A
5 meters
R2-U26 within Rack 2 R2-U26-P8A to R2-U1-P3B
R2-U26-P8B to R2-U1-P4B
R2-U26-P9A to R2-U1-P5B
5 meters
R2-U26 to Rack 1 R2-U26-P11A to R1-U1-P9B
R2-U26-P11B to R1-U1-P10B
5 meters
R2-U26 to Rack 3 R2-U26-P9B to R3-U1-P6B
R2-U26-P10A to R3-U1-P7B
R2-U26-P10B to R3-U1-P8B
5 meters
The following table shows the cable connections for the third spine switch (R3-U1) when
cabling three full racks together.
TABLE 26
Leaf Switch Connections for the Third Rack in a Three-Rack System
Leaf Switch Connection Cable Length
R3-U32 within Rack 3 R3-U32-P8A to R3-U1-P3A
R3-U32-P8B to R3-U1-P4A
R3-U32-P9A to R3-U1-P5A
5 meters
R3-U32 to Rack 1 R3-U32-P9B to R1-U1-P6A
R3-U32-P10A to R1-U1-P7A
R3-U32-P10B to R1-U1-P8A
5 meters
R3-U32 to Rack 2 R3-U32-P11A to R2-U1-P9A 5 meters
266 Oracle SuperCluster T5-8 Owner's Guide • May 2016
