Oracle SuperCluster T5-8 User Manual

Identifying InfiniBand Fabric Connections
Leaf Switch 1 Port To Device Device
Location
Device Port
U26 5A T5-8 No. 2 U18 PCIE-3 P2
U26 5B
T5-8 No. 1 U10 PCIE-16 P1
U26 6A T5-8 No. 1 (Full Rack) U10 PCIE-15 P1
U26 6B T5-8 No. 1 U10 PCIE-8 P1
U26 7A T5-8 No. 1 (Full Rack) U10 PCIE-7 P1
U26 7B
Exadata Storage Server No. 8
(Full Rack)
U41 PCIE-3 P2
U26 8A
IB leaf switch 2 U32 8A
U26 8B IB spine switch U1 1B
U26 9A IB leaf switch 2 U32 9B
U26 9B IB leaf switch 2 U32 9A
U26 10A IB leaf switch 2 U32 10B
U26 10B IB leaf switch 2 U32 10A
U26 11A IB leaf switch 2 U32 11B
U26 11B IB leaf switch 2 U32 11A
U26 12A
Exadata Storage Server No. 7
(Full Rack)
U39 PCIE-3 P1
U26 12B
T5-8 No. 1 (Full Rack) U10 PCIE-12 P1
U26 13A T5-8 No. 1 U10 PCIE-11 P1
U26 13B T5-8 No. 1 (Full Rack) U10 PCIE-4 P1
U26 14A T5-8 No. 1 U10 PCIE-3 P1
U26 14B
ZFS storage controller No. 1 U33 PCIE-0 P1
U26 15A
Exadata Storage Server No. 6
(Full Rack)
U37 PCIE-3 P2
U26 15B
Exadata Storage Server No. 5
(Full Rack)
U35 PCIE-3 P2
U26 16A
Exadata Storage Server No. 4 U8 PCIE-3 P2
U26 16B
Exadata Storage Server No. 3 U6 PCIE-3 P1
U26 17A
Exadata Storage Server No. 2 U4 PCIE-3 P1
U26 17B
Exadata Storage Server No. 1 U2 PCIE-3 P1
IB Leaf Switch No. 2
Leaf Switch 2 Port To Device Device
Location
Device Port
U32 0A T5-8 No. 2 U18 PCIE-16 P1
254 Oracle SuperCluster T5-8 Owner's Guide • May 2016
