Understanding Expansion Rack Internal Cabling
Rack Unit PDU-A/PS-00 PDU-B/PS-01 Cable Length
U18 G2-2 G5-4 2 meters
U16 G1-6 G4-0 2 meters
U14 G2-0 G5-6 2 meters
U12 G1-4 G4-2 2 meters
U10 G1-2 G4-4 2 meters
U8 G1-0 G4-6 2 meters
U6 G0-6 G3-0 2 meters
U4 G0-4 G3-2 2 meters
U2 G0-2 G3-4 2 meters
U1 G0-0 G3-6 2 meters
TABLE 82
Three-Phase PDU Cabling for the Expansion Rack (Quarter Rack)
Rack Unit PDU-A/PS-00 PDU-B/PS-01 Cable Length
U24 G3-1 G0-5 2 meters
U23 N/A G5-0 included
U22 G2-5 G5-1 1 meter
U21 G3-0 G0-6 2 meters
U20 G2-4 G5-2 2 meters
U8 G1-0 G4-6 2 meters
U6 G0-6 G3-0 2 meters
U4 G0-4 G3-2 2 meters
U2 G0-2 G3-4 2 meters
InfiniBand Network Cabling
This topic contains tables that list the InfiniBand network cabling. The Sun Datacenter
InfiniBand Switch 36 switches are located in located in rack unit 1, 20 and 24.
■
Table 82, “Three-Phase PDU Cabling for the Expansion Rack (Quarter Rack),” on page
311
■
Table 83, “InfiniBand Network Cabling for the Expansion Rack (Full Rack),” on page
312
■
Table 85, “InfiniBand Network Cabling for the Expansion Rack (Quarter Rack),” on page
314
Connecting Expansion Racks 311
