Connecting an Expansion Rack to Oracle SuperCluster T5-8
Leaf Switch Connection
R12 IB2 to Rack 6 R12-IB2-P14A to R6-IB1-P14B
R12 IB2 to Rack 7 R12-IB2-P14B to R7-IB1-P14B
R12 IB2 to Rack 8 R12-IB2-P8A to R8-IB1-P14B
Thirteen-Rack Cabling
The following table shows the cable connections for the switches when cabling thirteen racks
together.
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 126
Leaf Switch Connections for the Thirteenth Rack in the System
Leaf Switch Connection
R13 IB3 to Rack 1 R13-IB3-P8B to R1-IB1-P15A
R13 IB3 to Rack 2 R13-IB3-P9A to R2-IB1-P15A
R13 IB3 to Rack 3 R13-IB3-P9B to R3-IB1-P15A
R13 IB3 to Rack 4 R13-IB3-P10A to R4-IB1-P15A
R13 IB3 to Rack 5 R13-IB3-P10B to R5-IB1-P15A
R13 IB3 to Rack 6 R13-IB3-P15A to R6-IB1-P15A
R13 IB3 to Rack 7 R13-IB3-P15B to R7-IB1-P15A
R13 IB3 to Rack 8 R13-IB3-P8A to R8-IB1-P15A
R13 IB2 to Rack 1 R13-IB2-P8B to R1-IB1-P15B
R13 IB2 to Rack 2 R13-IB2-P9A to R2-IB1-P15B
R13 IB2 to Rack 3 R13-IB2-P9B to R3-IB1-P15B
R13 IB2 to Rack 4 R13-IB2-P10A to R4-IB1-P15B
R13 IB2 to Rack 5 R13-IB2-P10B to R5-IB1-P15B
R13 IB2 to Rack 6 R13-IB2-P15A to R6-IB1-P15B
R13 IB2 to Rack 7 R13-IB2-P15B to R7-IB1-P15B
R13 IB2 to Rack 8 R13-IB2-P8A to R8-IB1-P15B
Fourteen-Rack Cabling
The following table shows the cable connections for the switches when cabling fourteen racks
together.
348 Oracle SuperCluster T5-8 Owner's Guide • May 2016
