Understanding Expansion Rack Internal Cabling
TABLE 73
Oracle ILOM Cabling for the Expansion Rack (Quarter Rack)
From Rack Unit Type of Equipment Gigabit Ethernet Port
U8 Exadata Storage Server 38
U6 Exadata Storage Server 40
U4 Exadata Storage Server 42
U2 Exadata Storage Server 44
Administrative Gigabit Ethernet Port Cabling
Tables
This topic contains tables that list the administrative Gigabit Ethernet network cabling. The port
on the servers is labeled Net-0, and connects to the Gigabit Ethernet port located in rack unit 21
on the expansion racks.
■
Table 74, “Gigabit Ethernet Cabling for the Expansion Rack (Full Rack),” on page 306
■
Table 75, “Gigabit Ethernet Cabling for the Expansion Rack (Half Rack),” on page 307
■
Table 75, “Gigabit Ethernet Cabling for the Expansion Rack (Half Rack),” on page 307
TABLE 74
Gigabit Ethernet Cabling for the Expansion Rack (Full Rack)
From Rack Unit Type of Equipment Gigabit Ethernet Port
U41 Exadata Storage Server 1
U39 Exadata Storage Server 3
U37 Exadata Storage Server 5
U35 Exadata Storage Server 7
U33 Exadata Storage Server 9
U31 Exadata Storage Server 11
U29 Exadata Storage Server 13
U27 Exadata Storage Server 17
U25 Exadata Storage Server 21
U24 Sun Datacenter InfiniBand Switch 36 switch 45
U20 Sun Datacenter InfiniBand Switch 36 switch 46
U18 Exadata Storage Server 25
U16 Exadata Storage Server 29
U14 Exadata Storage Server 31
U12 Exadata Storage Server 33
U10 Exadata Storage Server 35
306 Oracle SuperCluster T5-8 Owner's Guide • May 2016
