Page #305 background imageLoading...
Page #305 background image
Understanding Expansion Rack Internal Cabling
Table 71, “Oracle ILOM Cabling for the Expansion Rack (Full Rack),” on page 305
Table 72, “Oracle ILOM Cabling for the Expansion Rack (Half Rack),” on page 305
Table 73, “Oracle ILOM Cabling for the Expansion Rack (Quarter Rack),” on page 306
TABLE 71
Oracle ILOM Cabling for the Expansion Rack (Full Rack)
From Rack Unit Type of Equipment Gigabit Ethernet Port
U41 Exadata Storage Server 2
U39 Exadata Storage Server 4
U37 Exadata Storage Server 6
U35 Exadata Storage Server 8
U33 Exadata Storage Server 10
U31 Exadata Storage Server 12
U29 Exadata Storage Server 14
U27 Exadata Storage Server 18
U25 Exadata Storage Server 22
U18 Exadata Storage Server 26
U16 Exadata Storage Server 30
U14 Exadata Storage Server 32
U12 Exadata Storage Server 34
U10 Exadata Storage Server 36
U8 Exadata Storage Server 38
U6 Exadata Storage Server 40
U4 Exadata Storage Server 42
U2 Exadata Storage Server 44
TABLE 72
Oracle ILOM Cabling for the Expansion Rack (Half Rack)
From Rack Unit Type of Equipment Gigabit Ethernet Port
U18 Exadata Storage Server 26
U16 Exadata Storage Server 30
U14 Exadata Storage Server 32
U12 Exadata Storage Server 34
U10 Exadata Storage Server 36
U8 Exadata Storage Server 38
U6 Exadata Storage Server 40
U4 Exadata Storage Server 42
U2 Exadata Storage Server 44
Connecting Expansion Racks 305
