Understanding Expansion Rack Internal Cabling
TABLE 78
Single-Phase PDU Cabling for the Expansion Rack (Half Rack)
Rack Unit PDU-A/PS-00 PDU-B/PS-01 Cable Length
U24 G3-1 G2-5 2 meters
U23 N/A G3-0 included
U22 G2-5 G3-1 1 meter
U21 G3-0 G2-6 2 meters
U20 G2-4 G3-2 2 meters
U18 G2-2 G3-4 2 meters
U16 G1-6 G4-0 2 meters
U14 G2-0 G3-6 2 meters
U12 G1-4 G4-2 2 meters
U10 G1-2 G4-4 2 meters
U8 G1-0 G4-6 2 meters
U6 G0-6 G5-0 2 meters
U4 G0-4 G5-2 2 meters
U2 G0-2 G5-4 2 meters
TABLE 79
Single-Phase PDU Cabling for the Expansion Rack (Quarter Rack)
Rack Unit PDU-A/PS-00 PDU-B/PS-01 Cable Length
U24 G3-1 G2-5 2 meters
U23 N/A G3-0 included
U22 G2-5 G3-1 1 meter
U21 G3-0 G2-6 2 meters
U20 G2-4 G3-2 2 meters
U8 G1-0 G4-6 2 meters
U6 G0-6 G5-0 2 meters
U4 G0-4 G5-2 2 meters
U2 G0-2 G5-4 2 meters
Three-Phase Power Distribution Unit Cabling
This topic contains tables that list the three-phase cabling from each PDU to the power supplies
configured in each rack. The cables are terminated to PDU-A on the left, and routed to the right
to enter CMA, and are bundled in groups of four.
■
Table 80, “Three-Phase PDU Cabling for the Expansion Rack (Full Rack),” on page 310
■
Table 81, “Three-Phase PDU Cabling for the Expansion Rack (Half Rack),” on page 310
Connecting Expansion Racks 309
