Expansion Rack Default IP Addresses
network and using the optional Fibre Channel PCIe cards do not apply for the Oracle Exadata
Storage Expansion Rack.
Expansion Rack Default IP Addresses
Component NET0 IP Addresses Oracle ILOM IP
Addresses
InfiniBand Bonded IP
Addresses
Exadata Storage Server 18 192.168.1.68 192.168.1.168 192.168.10.68
Exadata Storage Server 17 192.168.1.67 192.168.1.167 192.168.10.67
Exadata Storage Server 16 192.168.1.66 192.168.1.166 192.168.10.66
Exadata Storage Server 15 192.168.1.65 192.168.1.165 192.168.10.65
Exadata Storage Server 14 192.168.1.64 192.168.1.164 192.168.10.64
Exadata Storage Server 13 192.168.1.63 192.168.1.163 192.168.10.63
Exadata Storage Server 12 192.168.1.62 192.168.1.162 192.168.10.62
Exadata Storage Server 11 192.168.1.61 192.168.1.161 192.168.10.61
Exadata Storage Server 10 192.168.1.60 192.168.1.160 192.168.10.60
Exadata Storage Server 9 192.168.1.59 192.168.1.159 192.168.10.59
Exadata Storage Server 8 192.168.1.58 192.168.1.158 192.168.10.58
Exadata Storage Server 7 192.168.1.57 192.168.1.157 192.168.10.57
Exadata Storage Server 6 192.168.1.56 192.168.1.156 192.168.10.56
Exadata Storage Server 5 192.168.1.55 192.168.1.155 192.168.10.55
Exadata Storage Server 4 192.168.1.54 192.168.1.154 192.168.10.54
Exadata Storage Server 3 192.168.1.53 192.168.1.153 192.168.10.53
Exadata Storage Server 2 192.168.1.52 192.168.1.152 192.168.10.52
Exadata Storage Server 1 192.168.1.51 192.168.1.151 192.168.10.51
Sun Datacenter InfiniBand Switch 36 switch 3 192.168.1.223 NA NA
Sun Datacenter InfiniBand Switch 36 switch 2 192.168.1.222 NA NA
Sun Datacenter InfiniBand Switch 36 switch 1 192.168.1.221 NA NA
Ethernet switch 192.168.1.220 NA NA
PDU-A 192.168.1.212 NA NA
PDU-B 192.168.1.213 NA NA
Understanding Expansion Rack Internal Cabling
These topics show the cable layouts for the expansion rack.
300 Oracle SuperCluster T5-8 Owner's Guide • May 2016
