Oracle SuperCluster T5-8 User Manual

Connecting an Expansion Rack to Oracle SuperCluster T5-8
■
U32 in Oracle SuperCluster T5-8
■
U24 in the Oracle Exadata Storage Expansion Rack
The following sections provide information for connecting Oracle Exadata Storage Expansion
Half Rack or Oracle Exadata Storage Expansion Full Rack to your Oracle SuperCluster T5-8:
■
“Two-Rack Cabling” on page 322
■
“Three-Rack Cabling” on page 324
■
“Four-Rack Cabling” on page 326
■
“Five-Rack Cabling” on page 328
■
“Six-Rack Cabling” on page 332
■
“Seven-Rack Cabling” on page 336
■
“Eight-Rack Cabling” on page 340
■
“Nine-Rack Cabling” on page 345
■
“Ten-Rack Cabling” on page 345
■
“Eleven-Rack Cabling” on page 346
■
“Twelve-Rack Cabling” on page 347
■
“Thirteen-Rack Cabling” on page 348
■
“Fourteen-Rack Cabling” on page 348
■
“Fifteen-Rack Cabling” on page 349
■
“Sixteen-Rack Cabling” on page 350
■
“Seventeen-Rack Cabling” on page 351
■
“Eighteen-Rack Cabling” on page 351
Two-Rack Cabling
The following table shows the cable connections for the first spine switch (R1-IB1) when
cabling two racks together.
TABLE 87
Leaf Switch Connections for the First Rack in a Two-Rack System
Leaf Switch Connection Cable Length
R1-IB3 within Rack 1 R1-IB3-P8A to R1-IB1-P3A
R1-IB3-P8B to R1-IB1-P4A
R1-IB3-P9A to R1-IB1-P5A
R1-IB3-P9B to R1-IB1-P6A
5 meters
R1-IB3 to Rack 2 R1-IB3-P10A to R2-IB1-P7A 5 meters
322 Oracle SuperCluster T5-8 Owner's Guide • May 2016
