Oracle SuperCluster T5-8 User Manual

Connecting an Expansion Rack to Oracle SuperCluster T5-8
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 127
Leaf Switch Connections for the Fourteenth Rack in the System
Leaf Switch Connection
R14 IB3 to Rack 1 R14-IB3-P8B to R1-IB1-P16A
R14 IB3 to Rack 2 R14-IB3-P9A to R2-IB1-P16A
R14 IB3 to Rack 3 R14-IB3-P9B to R3-IB1-P16A
R14 IB3 to Rack 4 R14-IB3-P10A to R4-IB1-P16A
R14 IB3 to Rack 5 R14-IB3-P10B to R5-IB1-P16A
R14 IB3 to Rack 6 R14-IB3-P16A to R6-IB1-P16A
R14 IB3 to Rack 7 R14-IB3-P16B to R7-IB1-P16A
R14 IB3 to Rack 8 R14-IB3-P8A to R8-IB1-P16A
R14 IB2 to Rack 1 R14-IB2-P8B to R1-IB1-P16B
R14 IB2 to Rack 2 R14-IB2-P9A to R2-IB1-P16B
R14 IB2 to Rack 3 R14-IB2-P9B to R3-IB1-P16B
R14 IB2 to Rack 4 R14-IB2-P10A to R4-IB1-P16B
R14 IB2 to Rack 5 R14-IB2-P10B to R5-IB1-P16B
R14 IB2 to Rack 6 R14-IB2-P16A to R6-IB1-P16B
R14 IB2 to Rack 7 R14-IB2-P16B to R7-IB1-P16B
R14 IB2 to Rack 8 R14-IB2-P8A to R8-IB1-P16B
Fifteen-Rack Cabling
The following table shows the cable connections for the switches when cabling fifteen racks
together.
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 128
Leaf Switch Connections for the Fifteenth Rack in the System
Leaf Switch Connection
R15 IB3 to Rack 1 R15-IB3-P8B to R1-IB1-P17A
R15 IB3 to Rack 2 R15-IB3-P9A to R2-IB1-P17A
R15 IB3 to Rack 3 R15-IB3-P9B to R3-IB1-P17A
R15 IB3 to Rack 4 R15-IB3-P10A to R4-IB1-P17A
Connecting Expansion Racks 349
