Oracle SuperCluster T5-8 User Manual

Three-Phase PDU Cabling
Slot PDU-A/PSU-0
(T5-8 AC0)
PDU-B/PSU-0
(T5-8 AC2)
PDU-A/PSU-1
(T5-8 AC1)
PDU-B/PSU-1
(T5-8 AC3)
To Device
U35 Group 5-3 Group 0-3 — — Exadata Storage Server No. 5 (Full
Rack)
U34 Group 5-2 Group 0-4 — — ZFS storage controller No. 2
U33 Group 5-1 Group 0-5 — — ZFS storage controller No. 1
U32 Group 5-0 Group 0-6 — — Sun Datacenter InfiniBand Switch
36 Leaf Switch No. 2
U28 Group 4-6 Group 1-0 — — Sun Disk Shelf
U27 Group 3-5 Group 2-1 — — Ethernet management switch
U26 Group 3-6 Group 2-0 — — Sun Datacenter InfiniBand Switch
36 Leaf Switch No. 1
U18 Group 3-7 Group 2-7 Group 4-7 Group 1-7 SPARC T5-8 No. 2
U10 Group 1-7 Group 4-7 Group 2-7 Group 3-7 SPARC T5-8 No. 1
U8 Group 0-4 Group 5-2 — — Exadata Storage Server No. 4
U6 Group 0-3 Group 5-3 — — Exadata Storage Server No. 3
U4 Group 0-2 Group 5-4 — — Exadata Storage Server No. 2
U2 Group 0-1 Group 5-5 — — Exadata Storage Server No. 1
U1 Group 0-0 Group 5-6 — — Sun Datacenter InfiniBand Switch
36 Spine Switch
Three-Phase PDU Cabling
For three-phase AC power, connect the devices in the rack to the power distribution units
(PDUs) as shown in the following table. Each device requires two power cords for redundant
power.
Caution - Turn off all PDU circuit breakers before connecting power cords to the PDU. Every
socket group has a circuit breaker.
See Figure 31, “Circuit Breakers and AC Sockets on the PDU,” on page 252 for the locations
of the PDU circuit breakers and for names of the PDU AC sockets.
Slot PDU-A/PSU-0
(T5-8 AC0)
PDU-B/PSU-0
(T5-8 AC2)
PDU-A/PSU-1
(T5-8 AC1)
PDU-B/PSU-1
(T5-8 AC3)
To Device
U41 Group 5-6 Group 2-0 — — Exadata Storage Server No. 8 (Full
Rack)
U39 Group 5-5 Group 2-1 — — Exadata Storage Server No. 7 (Full
Rack)
Understanding Internal Cabling 259
