Three-Phase PDU Cabling
Slot PDU-A/PSU-0
(T5-8 AC0)
PDU-B/PSU-0
(T5-8 AC2)
PDU-A/PSU-1
(T5-8 AC1)
PDU-B/PSU-1
(T5-8 AC3)
To Device
U37 Group 5-4 Group 2-2 — — Exadata Storage Server No. 6 (Full
Rack)
U35 Group 5-3 Group 2-3 — — Exadata Storage Server No. 5 (Full
Rack)
U34 Group 5-2 Group 2-4 — — ZFS storage controller No. 2
U33 Group 5-1 Group 2-5 — — ZFS storage controller No. 1
U32 Group 5-0 Group 2-6 — — Sun Datacenter InfiniBand Switch
36 Leaf Switch No. 2
U28 Group 4-6 Group 1-0 — — Sun Disk Shelf
U27 Group 3-5 Group 0-1 — — Ethernet management switch
U26 Group 3-6 Group 0-0 — — Sun Datacenter InfiniBand Switch
36 Leaf Switch No. 1
U18 Group 3-7 Group 0-7 Group 4-7 Group 1-7 SPARC T5-8 No. 2
U10 Group 1-7 Group 4-7 Group 2-7 Group 5-7 SPARC T5-8 No. 1
U8 Group 0-4 Group 3-2 — — Exadata Storage Server No. 4
U6 Group 0-3 Group 3-3 — — Exadata Storage Server No. 3
U4 Group 0-2 Group 3-4 — — Exadata Storage Server No. 2
U2 Group 0-1 Group 3-5 — — Exadata Storage Server No. 1
U1 Group 0-0 Group 3-6 — — Sun Datacenter InfiniBand Switch
36 Spine Switch
260 Oracle SuperCluster T5-8 Owner's Guide • May 2016
