Oracle SuperCluster T5-8 User Manual

Connecting an Expansion Rack to Oracle SuperCluster T5-8
Leaf Switch Connection
R11 IB3 to Rack 5 R11-IB3-P10B to R5-IB1-P13A
R11 IB3 to Rack 6 R11-IB3-P13A to R6-IB1-P13A
R11 IB3 to Rack 7 R11-IB3-P13B to R7-IB1-P13A
R11 IB3 to Rack 8 R11-IB3-P8A to R8-IB1-P13A
R11 IB2 to Rack 1 R11-IB2-P8B to R1-IB1-P13B
R11 IB2 to Rack 2 R11-IB2-P9A to R2-IB1-P13B
R11 IB2 to Rack 3 R11-IB2-P9B to R3-IB1-P13B
R11 IB2 to Rack 4 R11-IB2-P10A to R4-IB1-P13B
R11 IB2 to Rack 5 R11-IB2-P10B to R5-IB1-P13B
R11 IB2 to Rack 6 R11-IB2-P13A to R6-IB1-P13B
R11 IB2 to Rack 7 R11-IB2-P13B to R7-IB1-P13B
R11 IB2 to Rack 8 R11-IB2-P8A to R8-IB1-P13B
Twelve-Rack Cabling
The following table shows the cable connections for the switches when cabling twelve racks
together.
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 125
Leaf Switch Connections for the Twelfth Rack in the System
Leaf Switch Connection
R12 IB3 to Rack 1 R12-IB3-P8B to R1-IB1-P14A
R12 IB3 to Rack 2 R12-IB3-P9A to R2-IB1-P14A
R12 IB3 to Rack 3 R12-IB3-P9B to R3-IB1-P14A
R12 IB3 to Rack 4 R12-IB3-P10A to R4-IB1-P14A
R12 IB3 to Rack 5 R12-IB3-P10B to R5-IB1-P14A
R12 IB3 to Rack 6 R12-IB3-P14A to R6-IB1-P14A
R12 IB3 to Rack 7 R12-IB3-P14B to R7-IB1-P14A
R12 IB3 to Rack 8 R12-IB3-P8A to R8-IB1-P14A
R12 IB2 to Rack 1 R12-IB2-P8B to R1-IB1-P14B
R12 IB2 to Rack 2 R12-IB2-P9A to R2-IB1-P14B
R12 IB2 to Rack 3 R12-IB2-P9B to R3-IB1-P14B
R12 IB2 to Rack 4 R12-IB2-P10A to R4-IB1-P14B
R12 IB2 to Rack 5 R12-IB2-P10B to R5-IB1-P14B
Connecting Expansion Racks 347
