Enable Cluster-Level Session Replication Enhancements
b.
Click WLS1 on the list of servers.
The Settings for WLS1 is displayed.
c.
Click the Cluster tab.
d.
In the Replication Ports field, enter a range of ports for configuring multiple
replication channels.
For example, replication channels for Managed Servers in Dept_1_Cluster1 can listen on
ports starting from 7005 to 7015. To specify this range of ports, enter 7005-7015.
3.
Create a custom network channel for each Managed Server in the cluster (for
example, WLS1) as follows:
a.
Log in to the Oracle WebLogic Server Administration Console.
b.
If you have not already done so, click Lock & Edit in the Change Center.
c.
In the left pane of the Console, expand Environment and select Servers.
The Summary of Servers page is displayed.
d.
In the Servers table, click WLS1 Managed Server instance.
e.
Select Protocols, and then Channels.
f.
Click New.
g.
Enter ReplicationChannel as the name of the new network channel and
select t3 as the protocol, then click Next.
h.
Enter the following information:
Listen address: 10.0.0.1
Note - This is the floating IP assigned to WLS1.
Listen port: 7005
i.
Click Next, and in the Network Channel Properties page, select Enabled and
Outbound Enabled.
232 Oracle SuperCluster T5-8 Owner's Guide • May 2016
