Enable Cluster-Level Session Replication Enhancements
j.
Click Finish.
k.
Under the Network Channels table, select ReplicationChannel, the network
channel you created for the WLS1 Managed Server.
l.
Expand Advanced, and select Enable SDP Protocol.
m.
Click Save.
n.
To activate these changes, in the Change Center of the Administration
Console, click Activate Changes.
You must repeat the above steps to create a network channel each for the remaining
Managed Servers in the Dept1_Cluster1 cluster. Enter the required properties, as described
in the following table.
Managed Servers in
Dept1_Cluster1
Name Protocol Listen Address Listen Port Additional Channel Ports
WLS2 ReplicationChannel t3 10.0.0.2 7005 7006 to 7014
WLS3 ReplicationChannel t3 10.0.0.3 7005 7006 to 7014
WLS4 ReplicationChannel t3 10.0.0.4 7005 7006 to 7014
WLS5 ReplicationChannel t3 10.0.0.5 7005 7006 to 7014
WLS6 ReplicationChannel t3 10.0.0.6 7005 7006 to 7014
WLS7 ReplicationChannel t3 10.0.0.7 7005 7006 to 7014
WLS8 ReplicationChannel t3 10.0.0.8 7005 7006 to 7014
4.
After creating the network channel for each of the Managed Servers in your
cluster, click Environment > Clusters. The Summary of Clusters page is
displayed.
5.
Click Dept1_Cluster1 (this is the example cluster to which you will deploy a web
application at a later time). The Settings for Dept1_Cluster1 page is displayed.
6.
Click the Replication tab.
7.
In the Replication Channel field, ensure that ReplicationChannel is set as the
name of the channel to be used for replication traffic.
8.
In the Advanced section, select the Enable One Way RMI for Replication option.
9.
Click Save.
Configuring Exalogic Software 233
