ZFS Storage Appliance Connections
ZFS Storage Appliance Connections
These connections are for these major components:
■
ZFS storage controller No. 1 (U33)
■
ZFS storage controller No. 2 (U34)
■
Sun Disk Shelf (U28)
From Storage
Controller Slot
Storage Controller Port To Slot To Port Cable
U33 PCIE-1 P0 U34 PCIE-1 P2 Yellow, 7 ft.
U33 PCIE-1 P1 U34 PCIE-1 P1 Black, 7 ft.
U33 PCIE-1 P2 U34 PCIE-1 P0 Green, 7 ft.
U34 PCIE-2 P1 U28 IOM0 P0 Black, 2 m
U33 PCIE-2 P1 U28 IOM0 P2 Black, 2 m
U34 PCIE-2 P0 U28 IOM1 P0 Black, 2 m
U33 PCIE-2 P0 U28 IOM1 P2 Black, 2 m
Single-Phase PDU Cabling
If the rack uses single-phase AC power, connect the devices in the rack to the power
distribution unit (PDU) as shown in the following table. Each device requires two power cords
for redundant power.
Caution - Turn off all PDU circuit breakers before connecting power cords to the PDU. Every
socket group has a circuit breaker.
See Figure 31, “Circuit Breakers and AC Sockets on the PDU,” on page 252 for the locations
of the PDU circuit breakers and for names of the PDU AC sockets.
Slot PDU-A/PSU-0
(T5-8 AC0)
PDU-B/PSU-0
(T5-8 AC2)
PDU-A/PSU-1
(T5-8 AC1)
PDU-B/PSU-1
(T5-8 AC3)
To Device
U41 Group 5-6 Group 0-0 — — Exadata Storage Server No. 8 (Full
Rack)
U39 Group 5-5 Group 0-1 — — Exadata Storage Server No. 7 (Full
Rack)
U37 Group 5-4 Group 0-2 — — Exadata Storage Server No. 6 (Full
Rack)
258 Oracle SuperCluster T5-8 Owner's Guide • May 2016
To Next Page
