Oracle SuperCluster T5-8 User Manual

Five-Rack Cabling
Leaf Switch Connection Cable Length
R4-U26-P11B to R3-U1-P10B
Five-Rack Cabling
The following table shows the cable connections for the first spine switch (R1-U1) when
cabling five full racks together.
TABLE 31
Leaf Switch Connections for the First Rack in a Five-Rack System
Leaf Switch Connection Cable Length
R1 U32 within Rack 1 R1-U32-P8A to R1-U1-P3A
R1-U32-P8B to R1-U1-P4A
3 meters
R1 U32 to Rack 2 R1-U32-P9A to R2-U1-P5A
R1-U32-P9B to R2-U1-P6A
5 meters
R1 U32 to Rack 3 R1-U32-P10A to R3-U1-P7A
R1-U32-P10B to R3-U1-P8A
5 meters
R1 U32 to Rack 4 R1-U32-P11A to R4-U1-P9A 10 meters
R1 U32 to Rack 5 R1-U32-P11B to R5-U1-P10A 10 meters
R1 U26 within Rack 1 R1-U26-P8A to R1-U1-P3B
R1-U26-P8B to R1-U1-P4B
3 meters
R1 U26 to Rack 2 R1-U26-P9A to R2-U1-P5B
R1-U26-P9B to R2-U1-P6B
3 meters
R1 U26 to Rack 3 R1-U26-P10A to R3-U1-P7B
R1-U26-P10B to R3-U1-P8B
5 meters
R1 U26 to Rack 4 R1-U26-P11A to R4-U1-P9B 10 meters
R1 U26 to Rack 5 R1-U26-P11B to R5-U1-P10B 10 meters
The following table shows the cable connections for the second spine switch (R2-U1) when
cabling five full racks together.
TABLE 32
Leaf Switch Connections for the Second Rack in a Five-Rack System
Leaf Switch Connection Cable Length
R2 U32 within Rack 2 R2-U32-P8A to R2-U1-P3A
R2-U32-P8B to R2-U1-P4A
3 meters
270 Oracle SuperCluster T5-8 Owner's Guide • May 2016
