Connecting an Expansion Rack to Oracle SuperCluster T5-8
Leaf Switch Connection
R16 IB2 to Rack 6 R16-IB2-P0A to R6-IB1-P0B
R16 IB2 to Rack 7 R16-IB2-P0B to R7-IB1-P0B
R16 IB2 to Rack 8 R16-IB2-P8A to R8-IB1-P0B
Seventeen-Rack Cabling
The following table shows the cable connections for the switches when cabling seventeen racks
together.
Note - Cable lengths for racks 9 through 18 vary depending on the layout of the racks. Up to
100 meters is supported.
TABLE 130
Leaf Switch Connections for the Seventeenth Rack in the System
Leaf Switch Connection
R17 IB3 to Rack 1 R17-IB3-P8B to R1-IB1-P1A
R17 IB3 to Rack 2 R17-IB3-P9A to R2-IB1-P1A
R17 IB3 to Rack 3 R17-IB3-P9B to R3-IB1-P1A
R17 IB3 to Rack 4 R17-IB3-P10A to R4-IB1-P1A
R17 IB3 to Rack 5 R17-IB3-P10B to R5-IB1-P1A
R17 IB3 to Rack 6 R17-IB3-P1A to R6-IB1-P1A
R17 IB3 to Rack 7 R17-IB3-P1B to R7-IB1-P1A
R17 IB3 to Rack 8 R17-IB3-P8A to R8-IB1-P1A
R17 IB2 to Rack 1 R17-IB2-P8B to R1-IB1-P1B
R17 IB2 to Rack 2 R17-IB2-P9A to R2-IB1-P1B
R17 IB2 to Rack 3 R17-IB2-P9B to R3-IB1-P1B
R17 IB2 to Rack 4 R17-IB2-P10A to R4-IB1-P1B
R17 IB2 to Rack 5 R17-IB2-P10B to R5-IB1-P1B
R17 IB2 to Rack 6 R17-IB2-P1A to R6-IB1-P1B
R17 IB2 to Rack 7 R17-IB2-P1B to R7-IB1-P1B
R17 IB2 to Rack 8 R17-IB2-P8A to R8-IB1-P1B
Eighteen-Rack Cabling
The following table shows the cable connections for the switches when cabling eighteen racks
together.
Connecting Expansion Racks 351
