Oracle SuperCluster T5-8 User Manual

Understanding Expansion Rack Internal Cabling
From Rack Unit Type of Equipment Gigabit Ethernet Port
U8 Exadata Storage Server 37
U6 Exadata Storage Server 39
U4 Exadata Storage Server 41
U2 Exadata Storage Server 43
U1 Sun Datacenter InfiniBand Switch 36 switch 47
PDU-A PDU 15
PDU-B PDU 19
TABLE 75
Gigabit Ethernet Cabling for the Expansion Rack (Half Rack)
From Rack Unit Type of Equipment Gigabit Ethernet Port
U24 Sun Datacenter InfiniBand Switch 36 switch 45
U20 Sun Datacenter InfiniBand Switch 36 switch 46
U18 Exadata Storage Server 25
U16 Exadata Storage Server 29
U14 Exadata Storage Server 31
U12 Exadata Storage Server 33
U10 Exadata Storage Server 35
U8 Exadata Storage Server 37
U6 Exadata Storage Server 39
U4 Exadata Storage Server 41
U2 Exadata Storage Server 43
U1 Sun Datacenter InfiniBand Switch 36 switch 47
PDU-A PDU 15
PDU-B PDU 19
TABLE 76
Gigabit Ethernet Cabling for the Expansion Rack (Quarter Rack)
From Rack Unit Type of Equipment Gigabit Ethernet Port
U24 Sun Datacenter InfiniBand Switch 36 switch 45
U20 Sun Datacenter InfiniBand Switch 36 switch 46
U8 Exadata Storage Server 37
U6 Exadata Storage Server 39
U4 Exadata Storage Server 41
U2 Exadata Storage Server 43
PDU-A PDU 15
PDU-B PDU 19
Connecting Expansion Racks 307
