Oracle SuperCluster T5-8 User Manual

Identifying InfiniBand Fabric Connections
Leaf Switch 2 Port To Device Device
Location
Device Port
U32 0B T5-8 No. 2 (Full Rack) U18 PCIE-15 P1
U32 1A T5-8 No. 2 U18 PCIE-8 P1
U32 1B T5-8 No. 2 (Full Rack) U18 PCIE-7 P1
U32 2A
— — —
U32 2B — — —
U32 3A
ZFS storage controller No. 2 U34 PCIE-0 P2
U32 3B
T5-8 No. 2 (Full Rack) U18 PCIE-12 P1
U32 4A T5-8 No. 2 U18 PCIE-11 P1
U32 4B T5-8 No. 2 (Full Rack) U18 PCIE-4 P1
U32 5A T5-8 No. 2 U18 PCIE-3 P1
U32 5B
T5-8 No. 1 U10 PCIE-16 P2
U32 6A T5-8 No. 1 (Full Rack) U10 PCIE-15 P2
U32 6B T5-8 No. 1 U10 PCIE-8 P2
U32 7A T5-8 No. 1 (Full Rack) U10 PCIE-7 P2
U32 7B
Exadata Storage Server No. 8
(Full Rack)
U41 PCIE 3 P1
U32 8A
IB leaf switch No. 1 U26 8A
U32 8B IB spine switch U1 0B
U32 9A IB leaf switch No. 1 U26 9B
U32 9B IB leaf switch No. 1 U26 9A
U32 10A IB leaf switch No. 1 U26 10B
U32 10B IB leaf switch No. 1 U26 10A
U32 11A IB leaf switch No. 1 U26 11B
U32 11B IB leaf switch No. 1 U26 11A
U32 12A
Exadata Storage Server No. 7
(Full Rack)
U39 PCIE 3 P2
U32 12B
T5-8 No. 1 (Full Rack) U10 PCIE-12 P2
U32 13A T5-8 No. 1 U10 PCIE-11 P2
U32 13B T5-8 No. 1 (Full Rack) U10 PCIE-4 P2
U32 14A T5-8 No. 1 U10 PCIE-3 P2
U32 14B
ZFS storage controller No. 1 U33 PCIE-0 P2
U32 15A
Exadata Storage Server No. 6
(Full Rack)
U37 PCIE 3 P1
U32 15B
Exadata Storage Server No. 5
(Full Rack)
U35 PCIE 3 P1
U32 16A
Exadata Storage Server No. 4 U8 PCIE 3 P1
U32 16B
Exadata Storage Server No. 3 U6 PCIE-3 P2
Understanding Internal Cabling 255
