Seven-Rack Cabling
Leaf Switch Connection Cable Length
R3 U26 to Rack 1 R3-U26-P11A to R1-U1-P9B 5 meters
R3 U26 to Rack 2 R3-U26-P11B to R2-U1-P10B 5 meters
R3 U26 to Rack 4 R3-U26-P9A to R4-U1-P5B 5 meters
R3 U26 to Rack 5 R3-U26-P9B to R5-U1-P6B 5 meters
R3 U26 to Rack 6 R3-U26-P10A to R6-U1-P7B 10 meters
R3 U26 to Rack 7 R3-U26-P10B to R7-U1-P8B 10 meters
The following table shows the cable connections for the fourth spine switch (R4-U1) when
cabling seven full racks together.
TABLE 45
Leaf Switch Connections for the Fourth Rack in a Seven-Rack System
Leaf Switch Connection Cable Length
R4 U32 within Rack 4 R4-U32-P8A to R4-U1-P3A
R4-U32-P8B to R4-U1-P4A
3 meters
R4 U32 to Rack 1 R4-U32-P10B to R1-U1-P8A 10 meters
R4 U32 to Rack 2 R4-U32-P11A to R2-U1-P9A 5 meters
R4 U32 to Rack 3 R4-U32-P11B to R3-U1-P10A 5 meters
R4 U32 to Rack 5 R4-U32-P9A to R5-U1-P5A 5 meters
R4 U32 to Rack 6 R4-U32-P9B to R6-U1-P6A 5 meters
R4 U32 to Rack 7 R4-U32-P10A to R7-U1-P7A 10 meters
R4 U26 within Rack 4 R4-U26-P8A to R4-U1-P3B
R4-U26-P8B to R4-U1-P4B
3 meters
R4 U26 to Rack 1 R4-U26-P10B to R1-U1-P8B 10 meters
R4 U26 to Rack 2 R4-U26-P11A to R2-U1-P9B 5 meters
R4 U26 to Rack 3 R4-U26-P11B to R3-U1-P10B 5 meters
R4 U26 to Rack 5 R4-U26-P9A to R5-U1-P5B 5 meters
R4 U26 to Rack 6 R4-U26-P9B to R6-U1-P6B 5 meters
R4 U26 to Rack 7 R4-U26-P10A to R7-U1-P7B 10 meters
The following table shows the cable connections for the fifth spine switch (R5-U1) when
cabling seven full racks together.
TABLE 46
Leaf Switch Connections for the Fifth Rack in a Seven-Rack System
Leaf Switch Connection Cable Length
R5 U32 within Rack 5 R5-U32-P8A to R5-U1-P3A 3 meters
Connecting Multiple Oracle SuperCluster T5-8 Systems 279
