Reviewing Power Requirements
Low Voltage Dual Phase (2W+GND) Comments
Outlet groups per PDU 6
Usable PDU power cord length 2 m (6.6 feet) PDU power cords are 4 m long (13 feet), but
sections are used for internal routing in the
rack.
Summary:
Number of PDUs in Oracle SuperCluster T5-8: 2
Number of circuits per PDU: 3 @ 50A 2-phase 208V
Total number of circuits required: 6 @ 50A 2-phase 208V (2 per PDU)
Total number of data center receptacles required: 6 x Hubbell CS8264C
Total Amps per PDU: 110.4A 2-phase 208V
Total Amps for entire Oracle SuperCluster T5-8: 220.8A 2-phase 208V (2 PDUs @ 110.4A 2-phase 208V each)
TABLE 8
Low Voltage 3 Phase PDUs
Low Voltage Three Phase (3W+GND) Comments
kVA Size 24 kVA
Marketing part number 6444A
Manufacturing part number 597-1162-01
Phase 3 No Grounded Neutral provided in input
cords
Voltage input rating 2x [3Ph. (3W+ground)] 208 Vac, 50/60 Hz,
max. 34.6A per phase
Can be connected to Ph-Ph input sources in
range of 190V - 220V AC nominal
Amps per PDU 120A (3 x 20A)
Outlets 42 C13
6 C19
Number of inputs 2 inputs x 60A plug, 3 ph (3W+GND) 2 inputs/plugs per PDU, or 4 total inputs/
plugs for system
Input current 34.6 A max. per phase
Data center receptacle IEC 309-3P4W-IP67 (60A, 250V, AC, 3Ph)
Outlet groups per PDU 6
Usable PDU power cord length 2 m (6.6 feet) PDU power cords are 4 m long (13 feet), but
sections are used for internal routing in the
rack.
Summary:
Number of PDUs in Oracle SuperCluster T5-8: 2
Number of circuits per PDU: 2 @ 60A 3-phase 208V
Total number of circuits required: 4 @ 60A 3-phase 208V (2 per PDU)
Total number of data center receptacles required: 4 x IEC 309-3P4W-IP67
Total Amps per PDU: 120A 3-phase 208V
102 Oracle SuperCluster T5-8 Owner's Guide • May 2016
