Oracle SuperCluster T5-8 User Manual

Reviewing Power Requirements
Low Voltage Three Phase (3W+GND) Comments
Total Amps for entire Oracle SuperCluster T5-8: 240A 3-phase 208V (2 PDUs @ 120A 3-phase 208V each)
TABLE 9
High Voltage 1 Phase PDUs
High Voltage Single Phase (2W+GND) Comments
kVA Size 22 kVA
Marketing part number 7100874
Manufacturing part number 7018124
Phase 1
Voltage input rating 3x [1Ph. (2W+ground)] 230 Vac, 50 Hz,
max. 32A per phase
Can be connected to Ph-N input sources in
range of 220V - 240V AC nominal
Amps per PDU 96A (3 inputs x 32A)
Outlets 42 C13
6 C19
Number of inputs 3 inputs x 32A plug, 1Ph (2W+ground) 3 inputs/plugs per PDU, or 6 total inputs/
plugs for system
Input current 32A max. current (per input)
Data center receptacle IEC 309-2P3W-IP44
Outlet groups per PDU 6
Usable PDU power cord length 2 m (6.6 feet) PDU power cords are 4 m long (13 feet), but
sections are used for internal routing in the
rack.
Summary:
Number of PDUs in Oracle SuperCluster T5-8: 2
Number of circuits per PDU: 3 @ 32A 1-phase 230V
Total number of circuits required: 6 @ 32A 1-phase 230V (2 per PDU)
Total number of data center receptacles required: 6 x IEC 309-2P3W-IP44
Total Amps per PDU: 96A 1-phase 230V
Total Amps for entire Oracle SuperCluster T5-8: 192A 1-phase 230V (2 PDUs @ 96A 1-phase 230V each)
TABLE 10
High Voltage 3 Phase PDUs
High Voltage Three Phase (4W+GND) Comments
kVA Size 24 kVA
Marketing part number 6445A
Manufacturing part number 597-1163-01
Phase 3
Voltage input rating 2x [3Ph. (4W+ground)] 230/400 Vac, 50/60
Hz, max. 18A per phase
Can be connected to Ph-N input sources in
range of 220V - 240V AC nominal
