Eight-Rack Cabling
TABLE 51
Leaf Switch Connections for the Third Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R3 U32 within Rack 3 R3-U32-P8A to R3-U1-P3A 3 meters
R3 U32 to Rack 1 R3-U32-P11A to R1-U1-P9A 5 meters
R3 U32 to Rack 2 R3-U32-P11B to R2-U1-P10A 5 meters
R3 U32 to Rack 4 R3-U32-P8B to R4-U1-P4A 5 meters
R3 U32 to Rack 5 R3-U32-P9A to R5-U1-P5A 5 meters
R3 U32 to Rack 6 R3-U32-P9B to R6-U1-P6A 5 meters
R3 U32 to Rack 7 R3-U32-P10A to R7-U1-P7A 10 meters
R3 U32 to Rack 8 R3-U32-P10B to R8-U1-P8A 10 meters
R3 U26 within Rack 3 R3-U26-P8A to R3-U1-P3B 3 meters
R3 U26 to Rack 1 R3-U26-P11A to R1-U1-P9B 5 meters
R3 U26 to Rack 2 R3-U26-P11B to R2-U1-P10B 5 meters
R3 U26 to Rack 4 R3-U26-P8B to R4-U1-P4B 5 meters
R3 U26 to Rack 5 R3-U26-P9A to R5-U1-P5B 5 meters
R3 U26 to Rack 6 R3-U26-P9B to R6-U1-P6B 5 meters
R3 U26 to Rack 7 R3-U26-P10A to R7-U1-P7B 10 meters
R3 U26 to Rack 8 R3-U26-P10B to R8-U1-P8B 10 meters
The following table shows the cable connections for the fourth spine switch (R4-U1) when
cabling eight full racks together.
TABLE 52
Leaf Switch Connections for the Fourth Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R4 U32 within Rack 4 R4-U32-P8A to R4-U1-P3A 3 meters
R4 U32 to Rack 1 R4-U32-P10B to R1-U1-P8A 10 meters
R4 U32 to Rack 2 R4-U32-P11A to R2-U1-P9A 5 meters
R4 U32 to Rack 3 R4-U32-P11B to R3-U1-P10A 5 meters
R4 U32 to Rack 5 R4-U32-P8B to R5-U1-P4A 5 meters
R4 U32 to Rack 6 R4-U32-P9A to R6-U1-P5A 5 meters
R4 U32 to Rack 7 R4-U32-P9B to R7-U1-P6A 10 meters
R4 U32 to Rack 8 R4-U32-P10A to R8-U1-P7A 10 meters
R4 U26 within Rack 4 R4-U26-P8A to R4-U1-P3B 3 meters
R4 U26 to Rack 1 R4-U26-P10B to R1-U1-P8B 10 meters
R4 U26 to Rack 2 R4-U26-P11A to R2-U1-P9B 5 meters
R4 U26 to Rack 3 R4-U26-P11B to R3-U1-P10B 5 meters
R4 U26 to Rack 5 R4-U26-P8B to R5-U1-P4B 5 meters
Connecting Multiple Oracle SuperCluster T5-8 Systems 283
