Connecting an Expansion Rack to Oracle SuperCluster T5-8
Leaf Switch Connection Cable Length
R2 IB3 to Rack 7 R2-IB3-P11A to R7-IB1-P9A 10 meters
R2 IB2 within Rack 2 R2-IB2-P8A to R2-IB1-P3B
R2-IB2-P8B to R2-IB1-P4B
3 meters
R2 IB2 to Rack 1 R2-IB2-P11B to R1-IB1-P10B 5 meters
R2 IB2 to Rack 3 R2-IB2-P9A to R3-IB1-P5B 5 meters
R2 IB2 to Rack 4 R2-IB2-P9B to R4-IB1-P6B 5 meters
R2 IB2 to Rack 5 R2-IB2-P10A to R5-IB1-P7B 10 meters
R2 IB2 to Rack 6 R2-IB2-P10Bto R6-IB1-P8B 10 meters
R2 IB2 to Rack 7 R2-IB2-P11A to R7-IB1-P9B 10 meters
The following table shows the cable connections for the third spine switch (R3-IB1) when
cabling seven full racks together.
TABLE 109
Leaf Switch Connections for the Third Rack in a Seven-Rack System
Leaf Switch Connection Cable Length
R3 IB3 within Rack 3 R3-IB3-P8A to R3-IB1-P3A
R3-IB3-P8B to R3-IB1-P4A
3 meters
R3 IB3 to Rack 1 R3-IB3-P11A to R1-IB1-P9A 5 meters
R3 IB3 to Rack 2 R3-IB3-P11B to R2-IB1-P10A 5 meters
R3 IB3 to Rack 4 R3-IB3-P9A to R4-IB1-P5A 5 meters
R3 IB3 to Rack 5 R3-IB3-P9B to R5-IB1-P6A 5 meters
R3 IB3 to Rack 6 R3-IB3-P10A to R6-IB1-P7A 10 meters
R3 IB3 to Rack 7 R3-IB3-P10B to R7-IB1-P8A 10 meters
R3 IB2 within Rack 3 R3-IB2-P8A to R3-IB1-P3B
R3-IB2-P8B to R3-IB1-P4B
3 meters
R3 IB2 to Rack 1 R3-IB2-P11A to R1-IB1-P9B 5 meters
R3 IB2 to Rack 2 R3-IB2-P11B to R2-IB1-P10B 5 meters
R3 IB2 to Rack 4 R3-IB2-P9A to R4-IB1-P5B 5 meters
R3 IB2 to Rack 5 R3-IB2-P9B to R5-IB1-P6B 5 meters
R3 IB2 to Rack 6 R3-IB2-P10A to R6-IB1-P7B 10 meters
R3 IB2 to Rack 7 R3-IB2-P10B to R7-IB1-P8B 10 meters
The following table shows the cable connections for the fourth spine switch (R4-IB1) when
cabling seven full racks together.
Connecting Expansion Racks 337
