Connecting an Expansion Rack to Oracle SuperCluster T5-8
Leaf Switch Connection Cable Length
R3 IB2 to Rack 4 R3-IB2-P8B to R4-IB1-P4B 5 meters
R3 IB2 to Rack 5 R3-IB2-P9A to R5-IB1-P5B 5 meters
R3 IB2 to Rack 6 R3-IB2-P9B to R6-IB1-P6B 5 meters
R3 IB2 to Rack 7 R3-IB2-P10A to R7-IB1-P7B 10 meters
R3 IB2 to Rack 8 R3-IB2-P10B to R8-IB1-P8B 10 meters
The following table shows the cable connections for the fourth spine switch (R4-IB1) when
cabling eight full racks together.
TABLE 117
Leaf Switch Connections for the Fourth Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R4 IB3 within Rack 4 R4-IB3-P8A to R4-IB1-P3A 3 meters
R4 IB3 to Rack 1 R4-IB3-P10B to R1-IB1-P8A 10 meters
R4 IB3 to Rack 2 R4-IB3-P11A to R2-IB1-P9A 5 meters
R4 IB3 to Rack 3 R4-IB3-P11B to R3-IB1-P10A 5 meters
R4 IB3 to Rack 5 R4-IB3-P8B to R5-IB1-P4A 5 meters
R4 IB3 to Rack 6 R4-IB3-P9A to R6-IB1-P5A 5 meters
R4 IB3 to Rack 7 R4-IB3-P9B to R7-IB1-P6A 10 meters
R4 IB3 to Rack 8 R4-IB3-P10A to R8-IB1-P7A 10 meters
R4 IB2 within Rack 4 R4-IB2-P8A to R4-IB1-P3B 3 meters
R4 IB2 to Rack 1 R4-IB2-P10B to R1-IB1-P8B 10 meters
R4 IB2 to Rack 2 R4-IB2-P11A to R2-IB1-P9B 5 meters
R4 IB2 to Rack 3 R4-IB2-P11B to R3-IB1-P10B 5 meters
R4 IB2 to Rack 5 R4-IB2-P8B to R5-IB1-P4B 5 meters
R4 IB2 to Rack 6 R4-IB2-P9A to R6-IB1-P5B 5 meters
R4 IB2 to Rack 7 R4-IB2-P9B to R7-IB1-P6B 10 meters
R4 IB2 to Rack 8 R4-IB2-P10A to R8-IB1-P7B 10 meters
The following table shows the cable connections for the fifth spine switch (R5-IB1) when
cabling eight full racks together.
TABLE 118
Leaf Switch Connections for the Fifth Rack in an Eight-Rack System
Leaf Switch Connection Cable Length
R5 IB3 within Rack 5 R5-IB3-P8A to R5-IB1-P3A 3 meters
R5 IB3 to Rack 1 R5-IB3-P10A to R1-IB1-P7A 10 meters
R5 IB3 to Rack 2 R5-IB3-P10B to R2-IB1-P8A 10 meters
R5 IB3 to Rack 3 R5-IB3-P11A to R3-IB1-P9A 5 meters
342 Oracle SuperCluster T5-8 Owner's Guide • May 2016
