E.1 ınnoRIID radEAGLE: Specifications radEAGLE User Manual
… continuation
Weight K L 2900 g (6 lb 6.3 oz) including batteries
Weight M 2400 g (5 lb 4.7 oz) including batteries
Weight N 2600 g (5 lb 11.7 oz) including batteries
Weight O 2420 g (5 lb 5.4 oz) including batteries
Weight P 2620 g (5 lb 12.4 oz) including batteries
Weight Q 2800 g (6 lb 2.8 oz) including batteries
Weight
R
3000 g (6 lb 9.8 oz) including batteries
Weight S 2820 g (6 lb 3.5 oz) including batteries
Weight T 3020 g (6 lb 10.5 oz) including batteries
Housing Material Aluminium; polyoxymethylene; glass
Environmental
Operating Temperature -20 °C — +55 °C (-4 °F — +131 °F)
Storage Temperature +10 °C — +35 °C (+50 °F — +95 °F)
Temperature Change Sudden temperature change must not exceed
30.0 °C (54.0 °F) in order to avoid damage to the
detector crystal.
Relative Humidity A—H M—T 10 % — 80 %, non condensing
Relative Humidity I—L ≤100 %
Shock Resistance 50 × g
Protection Rating A—H M—T IP65 according to IEC 60529
Protection Rating
I—L
IP68 according to IEC 60529; 15 m (49.21 ft)
Explosive Atmospheres NOT certified for use in explosive environments
Battery
Type powerCELL (LSD NiMH, rechargeable);
exchangeable
Capacity >2700 mAh; 7.2 V
Operating Duration ≥8.5 h at 20 °C (68 °F) in dose rate mode with
dimmed display back light and GPS switched off
Operating Duration ≥6 h at -20 °C (-4 °F) in dose rate mode with
dimmed display back light and GPS switched off
Charging Duration 3.5 h at 20 °C (68 °F) when instrument off
Display
Type Transflective color TFT LCD
Size 3.5 in (88.9 mm); 640 pixel × 480 pixel
Central Luminance 250 cd/m² (typical)
Annunciators
Red LED Gamma warning and alarm reporting; startup
indication
to be continued…
138/147 Software 3.2.12 • Document 3.3.0o © innoRIID GmbH • 2019-04-11
