1.5.4 Connectors
The radEAGLE has several connectors.
When operating under harsh conditions, keep the connectors clean and free of dust
or sand. If you experience connection problems, clean the connector with a cleanser
specialized for electronic components.
USB Mini-B at rear end
Use this plug (Fig. 2a, p. 15, Fig. 2b, p. 15) to connect your radEAGLE to a computer. All
common operating systems like Microsoft Windows, MacOS or Linux are supported.
USB-A host connector in the handle
Use this plug (Fig. 2a, p. 15) for Wi-Fi, Bluetooth, USB-to-Ethernet adaptors, or USB
storage devices (all optional).
Power plug on back side
Please align the red dot on the charger cable to that of the plug when connecting
(Fig. 2a, p. 15, Fig. 2b, p. 15, Fig. 140, p. 114).
© innoRIID GmbH • 2019-04-11 Software 3.2.12 • Document 3.3.0o 19/147
